mycom 220JS-V

2205B0JE-DA-J-N_2014.05.
5 Maintenance and Inspection
Screw Compressor J-series 5.4 Disassembly and Assembly of the Compressor
5-30
5.4.8.3 Precautions for Installation
 O-ring
1.
Make sure that all necessary O-rings are all attached.
 Mechanical seal assembly (mating ring)
1.
Attach the mating ring to the seal cover.
 Shower flushing sleeve
1.
Using eyebolts (M8), install the shower flashing sleeve.
 Seal cover assembly
1.
Lubricate the seal ring of the male rotor shaft
with lubricant.
2. Lubricate the mating ring of the seal cover
assembly with lubricant.
 Shaft key
1.
Check for damages. If anything wrong is found, replace the key.
