5 Maintenance and Inspection
Screw Compressor J-series 5.2 Maintenance List
5-7
5.2.4 Replacement Parts of the Compressor in Overhauling
Table 5-5 Overhaul Timings and Replacement Parts (170J)
Part
No.
Part Name
Qty.
Inspection Interval
Remarks
40,000 hours
or 5 years
80,000 hours
or 10 years
170J
30,000 hours
or 4 years
60,000 hours
or 8 years
S M L
20,000 hours
or 3 years
40,000 hours
or 6 years
93 Suction flange gaske
t
1
A
NSI＃300 5”
96 Discharge flange gaske
t
1
A
NSI＃300 3”
216 Lubrication flange gaske
t
1
A
NSI＃300 1”
251
Electromizer (Economizer)
flange gaske
t
1
ANSI＃300 1”
254
A
quamizer (Liquid injection)
flange gaske
t
1
ANSI＃300 3/4”
6 O-ring 1 JIS B 2401 P375
9-1 O-ring 1 JIS B 2401 P52
12 O-ring 1 JIS B 2401 P375
17-1 O-ring 1 JIS B 2401 P300
17-2 O-ring 1 JIS B 2401 P14
23 O-ring 2 JIS B 2401 G115
35-1 O-ring 1 JIS B 2401 G90
35-2 O-ring 1 JIS B 2401 G115
49 O-ring 1 JIS B 2401 G120
52-1 O-ring 1 JIS B 2401 G120
52-2 O-ring 1 JIS B 2401 G145
63-1 O-ring 2
A
S568
A
-258
63-2 O-ring 2 JIS B 2401 P14
65 O-ring 2 JIS B 2401 P130
73 O-ring 1 JIS B 2401 P32
75-1 O-ring 1 JIS B 2401 G135
75-2 O-ring 1 JIS B 2401 P14
82-1 O-ring 2 JIS B 2401 P10
A
82-2 O-ring 1 JIS B 2401 P16
100-1 O-ring 1
A
S568
A
-334
100-4 O-ring 1
A
S568
A
-227
295 O-ring 1 JIS B 2401 P52
298 O-ring 1 JIS B 2401 G135
299-1 O-ring 1 JIS B 2401 G100
299-2 O-ring 1
A
S568
A
-258
325-1 O-ring 3 JIS B 2401 P32
421 O-ring 2 2 - JIS B 2401 P32
432 O-ring 4 JIS B 2401 G100
433 O-ring 4 JIS B 2401 G75
494 O-ring 1 JIS B 2401 P155
561 O-ring 8 JIS B 2401 P12
657 O-ring 1 JIS B 2401 G100
713 O-ring 1 JIS B 2401 P12
714 O-ring 1 JIS B 2401 P6
717 O-ring 1 JIS B 2401 G25
