mycom 220JS-V

2205B0JE-DA-J-N_2014.05.
1 Safety
Screw Compressor J-series 1.2 Warnings
1-6
 Affixing Positions of Safety Labels
The figure below shows the affixing positions of safety labels.
The numbers in the figure correspond to the ones in Table1-2 Safety Label.
Figure 1-1 Safety Label Locations (170J/220J)
Figure 1-2 Safety Label Locations (280J)
