mycom 220JS-V User Manual

2205B0JE-DA-J-N_2014.05.
5 Maintenance and Inspection
Screw Compressor J-series 5.4 Disassembly and Assembly of the Compressor
5-24
 Before disassembly or assembly of the
casings and covers, first remove the uppe
r
two bolts and attach the stud bolts (safet
y
bolts) to prevent the casing from falling.

 Any casing or cover dropped may cause
injuries or damage to the compressor.
Always attach stud bolts before installing
or disassembling the casing or cover.
 To disassemble the casing, first loosen all bolts and then remove the parallel pin using two
service holes located in diagonal positions.
 Notice that the lock nut for the unloader push rod is harder to screw in because it is high friction
locking devices. To assemble the nut, use a locknut wrench.
 Use liquid gasket (for example, HERME
SEAL) or silicon grease for the suction
adapter tightening bolts.
