5-16 Install the First Half of Swing Arm

.
Table 5-3 Small Track Mounting Locations (12-1/4 inches)
Dim A Dim A
Reveal Butt Hinge Center Pivot
w/Finger Guard
Center Pivot
no Finger Guard
Reveal Butt Hinge Center Pivot
w/Finger Guard
Center Pivot
no Finger Guard
0 7-5/8” 8-3/16” 7-3/16” 4” 14” 14-11/16” 13-11/16”
1/4” 7-3/4” 8-3/8” 7-3/8” 4-1/4” 14-3/16” 14 -3/4” 13-3/4”
1/2” 7-15/16” 8-9/16” 7-9/16” 4-1/2” 14-7/16” 14-3/4” 13-3/4”
3/4” 8-1/8” 8-3/4” 7-3/4” 4-3/4”
14-1/2”
14-3/4” 13-3/4”
1” 8-5/16” 8-15/16” 7-15/16” 5” 14-3/4” 13-3/4”
1-1/4” 8-1/2” 9-1/8” 8-1/8” 5-1/4”
14-13/16” 13-13/16”
1-1/2’ 8-11/16” 9-5/16” 8-5/16” 5-1/2”
1-3/4” 8-7/8” 9-1/2” 8-1/2” 5-3/4”
2” 9-1/16” 9-3/4” 8-3/4” 6”
2-1/4” 9-1/4” 9-15/16” 8-15/16” 6-1/4”
2-1/2” 9-1/2” 10-1/8” 9-1/8” 6-1/2” 18-1/2”
2-3/4” 9-11/16” 10-3/8” 9-3/8” 6-3/4” 18-9/16” 18-7/8” 17-7/8”
3” 13-1/8” 10-9/16” 9-9/16” 7” 18-9/16” 18-7/8” 17-7/8”
3-1/4” 13-3/8” 14-1/16” 13-1/16” 7-1/4” 18-5/8” 18-15/16” 17-15/16”
3-1/2” 13-9/16” 14-1/4” 13-1/4” 7-1/2” 18-5/8” N/A N/A
3-3/4” 13-3/4” 14-1/2” 13-1/2”
Table 5-4 Large Track Mounting Locations (21 inches)
Dim A Dim A
Reveal Butt Hinge Center Pivot
w/Finger Guard
Center Pivot
no Finger Guard
Reveal Butt Hinge Center Pivot
w/Finger Guard
Center Pivot
no Finger Guard
7-1/2” N/A 14-1/2” 13-1/2” 10-1/2” 19-1/4” 14-9/16” 13-9/16”
7-3/4”
14-1/4”
14-9/16” 13-9/16” 10-3/4” 19-1/4” 19-5/8” 18-5/8”
8” 14-9/16” 13-9/16” 11” 19-1/4”
19-11/16” 18-11/16”
8-1/4” 14-5/8” 13-5/8” 11-1/4” 18-9/16”
8-1/2” 14-5/8” 13-5/8” 11-1/2”
19-5/16”
8-3/4” 14-5/8” 13-5/8” 11-3/4”
9” 14-5/8” 13-5/8” 12”
9-1/4” 14-5/8” 13-5/8” 12-1/4”
9-1/2” 14-5/8” 13-5/8” 12-1/2”
9-3/4” 14-5/8” 13-5/8” 12-3/4”
10” 14-9/16” 13-9/16” 13”
10-1/4” 14-3/16” 14-9/16” 13-9/16”
