NAD 375BEE C - Page 29

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
Q133 Transistor KSC2690AYSTU 31-02690-00 TO126/90/ECB
Q135 Transistor KSC2690AYSTU 31-02690-00 TO126/90/ECB
Q136 Transistor KSC2690AYSTU 31-02690-00 TO126/90/ECB
Q137 Transistor KSA1220AYSTU 31-01220-00 TO126/90/ECB
Q138 Transistor KSA1220AYSTU 31-01220-00 TO126/90/ECB
Q139 Transistor 2SA2121-O J31-02121-00 TO264/215/BCE
Q140 Transistor 2SA2121-O J31-02121-00 TO264/215/BCE
Q141 Transistor 2SA2121-O J31-02121-00 TO264/215/BCE
Q142 Transistor 2SA2121-O J31-02121-00 TO264/215/BCE
Q143 Transistor 2SC5949-O J31-05949-00 TO264/215/BCE
Q144 Transistor 2SC5949-O J31-05949-00 TO264/215/BCE
Q145 Transistor 2SC5949-O J31-05949-00 TO264/215/BCE
Q146 Transistor 2SC5949-O J31-05949-00 TO264/215/BCE
Q147 Transistor MPSA92 31-00092-00 TO92/100/EBC
Q148 Transistor 2SC2240-GR J31-02240-00 TO92/100/ECB
Q149 Transistor MPSA92 31-00092-00 TO92/100/EBC
Q150 Transistor MPSA92 31-00092-00 TO92/100/EBC
Q151 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q152 Transistor KSC2690AYSTU 31-02690-00 TO126/90/ECB
THERMAL SWITCH
CB101 THERMAL BRAKE ST-22 90C L TYPE JA07-70022-09 TO220AC/SURFACE
CB102 THERMAL BRAKE ST-22 80C L TYPE JA07-70022-08 TO220AC/SURFACE
IC
IC101 Shunt Regulator TL431 03-00431-02 TO-92
IC102 Shunt Regulator TL431 03-00431-02 TO-92
IC103 Shunt Regulator TL431 03-00431-02 TO-92
IC104 QUAD OP-AMP TL084CN 03-00084-00 DIP.100/14/W.300/L.750
RESISTOR
R101 Metal Film Resistor 475Ω, 1/6W, ±1% 07-24750-50 AX/.200X.080/.031
R102 Metal Film Resistor 10KΩ, 1/6W, 1% 07-21002-50 AX/.200X.080/.031
R103 Metal Film Resistor 549Ω, 1/6W, ±1% 07-25490-50 AX/.200X.080/.031
R104 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R105 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R106 Metal Film Resistor 24KΩ, 1/6W, ±5% 07-20243-50 AX/.200X.080/.031
R107 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R108 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R109 Metal Film Resistor 24KΩ, 1/6W, ±5% 07-20243-50 AX/.200X.080/.031
R110 Metal Film Resistor 1KΩ, 1/6W , 5% 07-20102-50 AX/.200X.080/.031
R111 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R112 Metal Film Resistor 39KΩ, 1/6W, ±5% 07-20393-50 AX/.200X.080/.031
R113 Metal Film Resistor 220KΩ, 1/6W, 5% 07-20224-50 AX/.200X.080/.031
R114 Metal Film Resistor 82Ω, 1/6W, 5% 07-20820-50 AX/.200X.080/.031
R115 Metal Film Resistor 15Ω, 1/6W, ±5% 07-20150-50 AX/.200X.080/.031
R116 Metal Film Resistor 24KΩ, 1/6W, ±5% 07-20243-50 AX/.200X.080/.031
R117 Metal Film Resistor 15Ω, 1/6W, ±5% 07-20150-50 AX/.200X.080/.031
R118 Metal Film Resistor 220KΩ, 1/6W, 5% 07-20224-50 AX/.200X.080/.031
R119 Metal Film Resistor 39KΩ, 1/6W, ±5% 07-20393-50 AX/.200X.080/.031
R120 Metal Film Resistor 82Ω, 1/6W, 5% 07-20820-50 AX/.200X.080/.031
R121 Metal Film Resistor 82Ω, 1/6W, 5% 07-20820-50 AX/.200X.080/.031
R122 Metal Film Resistor 100KΩ, 1/6W, 5% 07-20104-50 AX/.200X.080/.031
R123 Metal Film Resistor 82Ω, 1/6W, 5% 07-20820-50 AX/.200X.080/.031
R124 Metal Film Resistor 100KΩ, 1/6W, 5% 07-20104-50 AX/.200X.080/.031
R125 Metal Film Resistor 200Ω, 1/6W, ±5% 07-20201-50 AX/.400X.100/.031
R126 Metal Film Resistor 10Ω, 1/6W, 5% 07-20100-50 AX/.200X.080/.031
- 29 -
ELECTRICAL PARTS LIST
