NAD 375BEE C - Page 30

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
R127 Metal Film Resistor 10Ω, 1/6W, 5% 07-20100-50 AX/.200X.080/.031
R128 Metal Film Resistor 10Ω, 1/6W, 5% 07-20100-50 AX/.200X.080/.031
R129 Metal Film Resistor 10Ω, 1/6W, 5% 07-20100-50 AX/.200X.080/.031
R130 Metal Film Resistor 1KΩ, 1W, ±1% 07-21001-01 AX/.600X.125/.039
R132 Metal Film Resistor 2K2Ω, 1/6W , 5% 07-20222-50 AX/.200X.080/.031
R133 Metal Film Resistor 2.7KΩ, 1/6W, ±5% 07-20272-50 AX/.200X.080/.031
R135 Metal Film Resistor 2K2Ω, 1/6W , 5% 07-20222-50 AX/.200X.080/.031
R136 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-50 AX/.200X.080/.031
R137 Metal Film Resistor 1.5KΩ, 1/6W, ±1% 07-21501-50 AX/.200X.080/.031
R138 Metal Film Resistor 10KΩ, 1/6W, 1% 07-21002-50 AX/.200X.080/.031
R139 Metal Film Resistor 36KΩ, 1/6W, ±1% 07-23602-50 AX/.200X.080/.031
R140 Metal Oxide Film Resistor 3.9KΩ, 3W, ±5% 07-30392-03 AX/.600X.125/.039
R141 Metal Oxide Film Resistor 3.9KΩ, 3W, ±5% 07-30392-03 AX/.600X.125/.039
R142 Metal Film Resistor 330Ω, 1/4W, ±5% 07-20331-51 AX/.400X.100/.031
R143 Metal Film Resistor 3.3Ω, 1/4W , ±5% 07-20339-51 AX/.400X.100/.031
R144 Metal Film Resistor 3.3Ω, 1/4W , ±5% 07-20339-51 AX/.400X.100/.031
R145 Metal Film Resistor 330Ω, 1/4W, ±5% 07-20331-51 AX/.400X.100/.031
R146 Metal Oxide Film Resistor 3.9KΩ, 3W, ±5% 07-30392-03 AX/.600X.125/.039
R147 Metal Oxide Film Resistor 3.9KΩ, 3W, ±5% 07-30392-03 AX/.600X.125/.039
R148 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R149 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R150 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R151 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R152 Metal Film Resistor 845Ω, 1W, ±1% 07-28450-01 AX/.600X.125/.039
R153 Metal Film Resistor 1.8MΩ, 1/6W, ±5% 07-20185-50 AX/.200X.080/.031
R154 Metal Film Resistor 1.2KΩ, 1/6W, ±5% 07-20122-50 AX/.200X.080/.031
R155 Metal Film Resistor 4.7Ω, 1/6W , ±5% 07-20479-50 AX/.200X.080/.031
R156 Metal Film Resistor 33Ω, 1/6W, 5% 07-20330-50 AX/.200X.080/.031
R157 Metal Film Resistor 3K3Ω, 1/6W , 5% 07-20332-50 AX/.200X.080/.031
R158 Metal Film Resistor 910Ω, 1/6W, ±5% 07-20911-50 AX/.200X.080/.031
R159 Metal Film Resistor 1KΩ, 1W, ±1% 07-21001-01 AX/.600X.125/.039
R160 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R161 Metal Film Resistor 4.7Ω, 1/6W , ±5% 07-20479-50 AX/.200X.080/.031
R162 Metal Film Resistor 33Ω, 1/6W, 5% 07-20330-50 AX/.200X.080/.031
R163 Metal Film Resistor 15Ω, 1/4W, ±5% 07-20150-51 AX/.400X.100/.031
R164 Metal Film Resistor 18Ω, 1/4W, ±5% 07-20180-51 AX/.400X.100/.031
R165 Metal Oxide Film Resistor 1Ω, 1/2W, ±5% 07-30109-00 AX/.600X.125/.039
R166 Metal Oxide Film Resistor 1Ω, 1/2W, ±5% 07-30109-00 AX/.600X.125/.039
R167 Metal Film Resistor 22Ω, 1/6W, ±5% 07-20220-50 AX/.200X.080/.031
R168 Metal Oxide Film Resistor 1Ω, 1/2W, ±5% 07-30109-00 AX/.600X.125/.039
R169 Metal Oxide Film Resistor 1Ω, 1/2W, ±5% 07-30109-00 AX/.600X.125/.039
R170 Metal Film Resistor 18Ω, 1/4W, ±5% 07-20180-51 AX/.400X.100/.031
R171 Metal Film Resistor 15Ω, 1/4W, ±5% 07-20150-51 AX/.400X.100/.031
R172 Cement Resistor 0.22Ω, 5W, ±5% 07-40228-15 RAD/RES/.520X.200/LS.400/.039
R173 Cement Resistor 0.22Ω, 5W, ±5% 07-40228-15 RAD/RES/.520X.200/LS.400/.039
R174 Cement Resistor 0.22Ω, 5W, ±5% 07-40228-15 RAD/RES/.520X.200/LS.400/.039
R175 Cement Resistor 0.22Ω, 5W, ±5% 07-40228-15 RAD/RES/.520X.200/LS.400/.039
R176 Metal Film Resistor 10KΩ, 1/4W, ±5% 07-20103-51 AX/.400X.100/.031
R177 Metal Oxide Film Resistor 10Ω, 2W, ±5% 07-30100-12 AX/.600X.125/.039
R178 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R179 Cement Resistor 0.22Ω, 5W, ±5% 07-40228-15 RAD/RES/.520X.200/LS.400/.039
R180 Cement Resistor 0.22Ω, 5W, ±5% 07-40228-15 RAD/RES/.520X.200/LS.400/.039
R181 Cement Resistor 0.22Ω, 5W, ±5% 07-40228-15 RAD/RES/.520X.200/LS.400/.039
R182 Cement Resistor 0.22Ω, 5W, ±5% 07-40228-15 RAD/RES/.520X.200/LS.400/.039
R183 Metal Film Resistor 47KΩ, 1/6W, 5% 07-20473-50 AX/.200X.080/.031
- 30 -
ELECTRICAL PARTS LIST
