NAD 375BEE C - Page 31

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
R184 Metal Film Resistor 470Ω, 1/6W, 5% 07-20471-50 AX/.200X.080/.031
R185 Metal Film Resistor 47KΩ, 1/6W, 5% 07-20473-50 AX/.200X.080/.031
R186 Metal Film Resistor 22KΩ, 1/6W, 5% 07-20223-50 AX/.200X.080/.031
R187 Metal Film Resistor 2K2Ω, 1/6W , 5% 07-20222-50 AX/.200X.080/.031
R188 Metal Film Resistor 33KΩ, 1/6W, ±5% 07-20333-50 AX/.200X.080/.031
R189 Metal Film Resistor 22KΩ, 1/6W, 5% 07-20223-50 AX/.200X.080/.031
R190 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R191 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R192 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R193 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R194 Fusible Resistor 10Ω, 1W, ±5% 07-50100-01 AX/.600X.125/.039
R195 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R196 Metal Film Resistor 100KΩ, 1/6W, 5% 07-20104-50 AX/.200X.080/.031
R197 Metal Film Resistor 100KΩ, 1/6W, 5% 07-20104-50 AX/.200X.080/.031
R198 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R199 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R1A1 Metal Film Resistor 24.3KΩ, 1/6W, ±1% 07-22432-50 AX/.200X.080/.031
R1A2 Metal Film Resistor 7.32KΩ, 1/6W, ±1% 07-27321-50 AX/.200X.080/.031
R1A3 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R1A4 Fusible Resistor 10Ω, 1W, ±5% 07-50100-01 AX/.600X.125/.039
R1A5 Metal Film Resistor 100KΩ, 1/6W , 5% 07-20104-50 AX/.200X.080/.031
R1A6 Metal Film Resistor 100KΩ, 1/6W , 5% 07-20104-50 AX/.200X.080/.031
R1A8 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-50 AX/.200X.080/.031
R1A9 Metal Film Resistor 7.32KΩ, 1/6W, ±1% 07-27321-50 AX/.200X.080/.031
R1E1 Metal Film Resistor 24.3KΩ, 1/6W, ±1% 07-22432-50 AX/.200X.080/.031
R1E2 Metal Film Resistor 1megΩ, 1/6W, 5% 07-20105-50 AX/.200X.080/.031
R1E3 Cement Resistor 0.05Ω, 3W, ±5% 07-40507-03 RAD/RES/.520X.200/LS.400/.039
R1E4 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R1E5 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R1E6 Metal Film Resistor 9.1KΩ, 1/6W , ±5% 07-20912-50 AX/.200X.080/.031
R1E7 Metal Film Resistor 560KΩ, 1/6W, ±5% 07-20564-50 AX/.200X.080/.031
R1E8 Metal Film Resistor 100KΩ, 1/6W , 5% 07-20104-50 AX/.200X.080/.031
R1E9 Metal Film Resistor 330KΩ, 1/6W, ±5% 07-20334-50 AX/.200X.080/.031
R1F1 Metal Film Resistor 22KΩ, 1/6W, 5% 07-20223-50 AX/.200X.080/.031
R1F2 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R1F3 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R1F4 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R1F5 Metal Film Resistor 270KΩ, 1/6W, ±1% 07-22703-50 AX/.200X.080/.031
R1F6 Metal Film Resistor 4.7MΩ, 1/6W, ±5% 07-20475-50 AX/.200X.080/.031
R1F7 Metal Film Resistor 470KΩ, 1/6W, ±1% 07-24703-50 AX/.200X.080/.031
R1F8 Metal Film Resistor 390KΩ, 1/6W, ±1% 07-23903-50 AX/.200X.080/.031
R1F9 Metal Film Resistor 110KΩ, 1/6W, ±1% 07-21103-50 AX/.200X.080/.031
R1G1 Metal Film Resistor 100KΩ, 1/6W , 5% 07-20104-50 AX/.200X.080/.031
R1G2 Metal Film Resistor 220KΩ, 1/6W , 5% 07-20224-50 AX/.200X.080/.031
R1G3 Metal Film Resistor 1KΩ, 1/6W , 5% 07-20102-50 AX/.200X.080/.031
R1G4 Metal Film Resistor 1megΩ, 1/6W, 5% 07-20105-50 AX/.200X.080/.031
R1G5 Metal Film Resistor 1megΩ, 1/6W, 5% 07-20105-50 AX/.200X.080/.031
R1H1 Metal Film Resistor 10KΩ, 1/6W , 5% 07-20103-50 AX/.200X.080/.031
R1H2 Metal Film Resistor 63.4Ω, 1/4W, ±1% 07-26349-51 AX/.400X.100/.031
R1H3 Metal Film Resistor 1KΩ, 1W , ±1% 07-21001-01 AX/.600X.125/.039
R1N1 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R1N7 Metal Film Resistor 1KΩ, 1/6W , 5% 07-20102-50 AX/.200X.080/.031
R1N8 Metal Film Resistor 1KΩ, 1/6W , 5% 07-20102-50 AX/.200X.080/.031
CAPACTIOR
C101 Polyester capacitor 100nF, ±5%, 250V 25-10422-01 RAD/CAP/.300X.150/LS.200/.031
- 31 -
ELECTRICAL PARTS LIST
