DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
C102 Polyester capacitor 100nF, ±5%, 250V 25-10422-01 RAD/CAP/.300X.150/LS.200/.031
C103 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C104 Ceramic Capacitor 33pF, ±5%, 1KV 05-33013-02 CPAX/.200X.100/.031
C105 ALU Electrolytic Capacitor
10uF/100V, ±20%, 105
06-10012-01 CPCYL1/D.300/LS.200/.031
C107 ALU Electrolytic Capacitor
10uF/100V, ±20%, 105
06-10012-01 CPCYL1/D.300/LS.200/.031
C108 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C109 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C110 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C111 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C112 Ceramic Capacitor 47pF, ±5%, 1KV 05-47013-01 CPAX/.200X.100/.031
C113 Ceramic Capacitor 120pF, ±5%, 1KV 05-12113-00 CPAX/.200X.100/.031
C114 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C115 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C116 Ceramic Capacitor 33pF, ±5%, 1KV 05-33013-02 CPAX/.200X.100/.031
C118 ALU Electrolytic Capacitor
10uF/100V, ±20%, 105
06-10012-01 CPCYL1/D.300/LS.200/.031
C119 ALU Electrolytic Capacitor
10uF/100V, ±20%, 105
06-10012-01 CPCYL1/D.300/LS.200/.031
C120 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C121 Ceramic Capacitor 22pF, ±5%, 1KV 05-22013-02 CPAX/.200X.100/.031
C122 Ceramic Capacitor 22pF, ±5%, 1KV 05-22013-02 CPAX/.200X.100/.031
C123 Ceramic Capacitor 22pF, ±5%, 1KV 05-22013-02 CPAX/.200X.100/.031
C124 Ceramic Capacitor 430pF, ±5%, 1KV 05-43113-01 CPAX/.200X.100/.031
C125 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C126 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C127 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C128 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C129 ALU Electrolytic Capacitor
47uF/25V, ±20%, 105
06-47021-01 CPCYL1/D.300/LS.200/.031
C130 ALU Electrolytic Capacitor
47uF/25V, ±20%, 105
06-47021-01 CPCYL1/D.300/LS.200/.031
C131 Polyester capacitor 100nF, ±5%, 100V 25-10412-04 RAD/CAP/.300X.150/LS.200/.031
C132 Ceramic Capacitor 220pF, ±10%, 1KV 05-22113-01 CPAX/.200X.100/.031
C134 Ceramic Capacitor 470pF, ±5%, 1KV 05-47113-02 CPAX/.200X.100/.031
C135 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C136 Ceramic Capacitor 470pF, ±5%, 1KV 05-47113-02 CPAX/.200X.100/.031
C138 Ceramic Capacitor 220pF, ±10%, 1KV 05-22113-01 CPAX/.200X.100/.031
C139 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C141 ALU Electrolytic Capacitor
4.7uF/50V, ±20%, 105
06-47951-05 CPCYL/D.200/LS.200/.031
C142 Polyester capacitor 100nF, ±5%, 100V 25-10412-04 RAD/CAP/.300X.150/LS.200/.031
C143 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C144 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C145 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C146 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105

06-
10051-01 CPCYL1/D.200/LS.200/.031
- 32 -
ELECTRICAL PARTS LIST
