NAD 375BEE C - Page 36

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
R271 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-50 AX/.200X.080/.031
R272 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-50 AX/.200X.080/.031
R273 Metal Film Resistor 2K2Ω, 1/6W , 5% 07-20222-50 AX/.200X.080/.031
R274 Metal Film Resistor 150KΩ, 1/6W, ±5% 07-20154-50 AX/.200X.080/.031
R275 Metal Film Resistor 22KΩ, 1/6W , 5% 07-20223-50 AX/.200X.080/.031
R276 Metal Film Resistor 82KΩ, 1/6W , ±5% 07-20823-50 AX/.200X.080/.031
R277 Metal Film Resistor 150KΩ, 1/6W, ±5% 07-20154-50 AX/.200X.080/.031
R278 Metal Film Resistor 33KΩ, 1/6W , ±5% 07-20333-50 AX/.200X.080/.031
R279 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R280 Metal Oxide Film Resistor 270Ω, 2W, ±5% 07-30271-12 AX/.600X.125/.039
R281 Metal Oxide Film Resistor 270Ω, 2W, ±5% 07-30271-12 AX/.600X.125/.039
R282 Metal Oxide Film Resistor 3.3Ω, 1W, ±5% 07-30339-04 AX/.600X.125/.039
R283 Metal Oxide Film Resistor 3.3Ω, 1W, ±5% 07-30339-04 AX/.600X.125/.039
R284 Metal Oxide Film Resistor 270Ω, 2W, ±5% 07-30271-12 AX/.600X.125/.039
R285 Metal Film Resistor 6.8KΩ, 1/6W , ±5% 07-20682-50 AX/.200X.080/.031
R286 Metal Film Resistor 10Ω, 1/4W, ±5% 07-20100-51 AX/.400X.100/.031
R287 Metal Film Resistor 10Ω, 1/6W, 5% 07-20100-50 AX/.200X.080/.031
R288 Metal Film Resistor 4.99KΩ, 1/6W , ±1% 07-24991-50 AX/.200X.080/.031
R289 Metal Film Resistor 4.7KΩ, 1/6W , ±1% 07-24701-50 AX/.200X.080/.031
R291 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R292 Metal Film Resistor 4.7KΩ, 1/6W, ±5% 07-20472-50 AX/.200X.080/.031
R293 Metal Oxide Film Resistor 180Ω, 2W, ±5% 07-30181-02 AX/.600X.125/.039
R294 Metal Film Resistor 820Ω, 1/6W, ±5% 07-20821-50 AX/.200X.080/.031
R295 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R296 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R297 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R298 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R299 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R2A1 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R2A2 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R2A3 Metal Film Resistor 33Ω, 1/6W, 5% 07-20330-50 AX/.200X.080/.031
R2A4 Metal Film Resistor 10KΩ, 1/6W , 5% 07-20103-50 AX/.200X.080/.031
R2A5 Metal Film Resistor 10Ω, 1/6W, 5% 07-20100-50 AX/.200X.080/.031
R2A6 Metal Film Resistor 47KΩ, 1/6W , 5% 07-20473-50 AX/.200X.080/.031
R2A7 Metal Film Resistor
330, 1/6W, 5%
07-20331-50 AX/.200X.080/.031
R2E1 Metal Film Resistor 2.67KΩ, 1/6W, ±1% 07-22671-50 AX/.200X.080/.031
R2E2 Metal Film Resistor 240Ω, 1/6W, ±1% 07-22400-50 AX/.200X.080/.031
R2E3 Metal Film Resistor 2.67KΩ, 1/6W, ±1% 07-22671-50 AX/.200X.080/.031
R2E4 Metal Film Resistor 240Ω, 1/6W, ±1% 07-22400-50 AX/.200X.080/.031
R2E5 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R2E6 Metal Film Resistor 2K2Ω, 1/6W , 5% 07-20222-50 AX/.200X.080/.031
R2E7 Metal Film Resistor 10KΩ, 1/6W , 5% 07-20103-50 AX/.200X.080/.031
R2E8 Metal Film Resistor 15KΩ, 1/6W , ±5% 07-20153-50 AX/.200X.080/.031
CAPACTIOR
C201 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C202 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C203 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C204 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C205 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C206 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C207 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C208 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C209 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C210 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C211 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
- 36 -
ELECTRICAL PARTS LIST
