NAD 375BEE C - Page 37

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
C212 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C213 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C214 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C215 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C216 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C217 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C218 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C219 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C220 Ceramic Capacitor 100pF, ±5%, 1KV 05-10113-04 CPAX/.200X.100/.031
C221 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C222 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C223 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C224 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C225 Ceramic Capacitor 220pF, ±10%, 1KV 05-22113-01 CPAX/.200X.100/.031
C226 Ceramic Capacitor 220pF, ±10%, 1KV 05-22113-01 CPAX/.200X.100/.031
C227 Polyester capacitor 10nF, ±5%, 250V 25-10322-02 RAD/CAP/.300X.150/LS.200/.031
C228 Polyester capacitor 10nF, ±5%, 250V 25-10322-02 RAD/CAP/.300X.150/LS.200/.031
C229 ALU Electrolytic Capacitor 10uF/100V, ±20%, 105 06-10012-01 CPCYL1/D.200/LS.200/.031
C230 ALU Electrolytic Capacitor 10uF/100V, ±20%, 105 06-10012-01 CPCYL1/D.200/LS.200/.031
C231 Polyester capacitor 100nF, ±5%, 100V 25-10412-04 RAD/CAP/.300X.150/LS.200/.031
C232 Polyester capacitor 100nF, ±5%, 100V 25-10412-04 RAD/CAP/.300X.150/LS.200/.031
C233 ALU Electrolytic Capacitor
22000uF, ±20%, 100V, 105
06-22312-01 CPCYL1/D2.165/LS.965/.079
C234 ALU Electrolytic Capacitor
22000uF, ±20%, 100V, 105
06-22312-01 CPCYL1/D2.165/LS.965/.079
C239 Polyester capacitor 10nF, ±5%, 250V 25-10322-02 RAD/CAP/.300X.150/LS.200/.031
C240 Polyester capacitor 10nF, ±5%, 250V 25-10322-02 RAD/CAP/.300X.150/LS.200/.031
C241 ALU Electrolytic Capacitor
2200uF, 63V, ±20%, 105
06-22261-00 CPCYL1/D.900/LS.400/.062
C242 ALU Electrolytic Capacitor
2200uF, 63V, ±20%, 105
06-22261-00 CPCYL1/D.900/LS.400/.062
C243 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C244 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C245 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C246 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C247 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C248 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C249 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C250 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C251 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C252 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C253 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C254 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C255 ALU Electrolytic Capacitor
1000uF, ±20%, 160V, 105

06-
10212-04 CPCYL1/D.900/LS.400/.062
C256 ALU Elect
rolytic Capacitor
1000uF, ±20%, 160V, 105
06-10212-04 CPCYL1/D.900/LS.400/.062
C257 Polyester capacitor 100nF, ±5%, 250V 25-10422-01 RAD/.300X.150/LS.200/.034
- 37 -
ELECTRICAL PARTS LIST
