DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
C258 Polyester capacitor 100nF, ±5%, 250V 25-10422-01 RAD/.300X.150/LS.200/.034
C259 ALU Electrolytic Capacitor
1uF/50V, ±20%, 105
06-10951-03 CPCYL1/D.200/LS.200/.031
C260 ALU Electrolytic Capacitor
100uF/16V, ±20%, 105
06-10111-07 CPCYL1/D.200/LS.200/.031
C261 ALU Electrolytic Capacitor
330uF, ±20%, 16V, 105
06-33111-02 CPCYL1/D.300/LS.200/.031
C262 Polyester capacitor 220nF, ±5%, 63V 25-22461-02 RAD/CAP/.300X.250/LS.200/.031
C263 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C264
Bi-polarized Alu
Electrolytic Capacitor
10uF, ±20%, 50V, 105
06-10051-11 CPCYL1/D.200/LS.200/.031
C269 Polyester capacitor 10nF, ±5%, 63V 25-10361-02 RAD/CAP/.300X.150/LS.200/.031
C270 Polyester capacitor 10nF, ±5%, 63V 25-10361-02 RAD/CAP/.300X.150/LS.200/.031
C271 ALU Electrolytic Capacitor
47uF/16V, ±20%, 105
06-47011-00 CPCYL1/D.200/LS.200/.031
C272 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C273 Polyester capacitor 10nF, ±5%, 63V 25-10361-02 RAD/CAP/.300X.150/LS.200/.031
C274 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C275 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C276 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C277 ALU Electrolytic Capacitor
1000uF, ±20%, 50V, 105
06-10251-01 CPCYL1/D.640/LS.300/.031
C278 ALU Electrolytic Capacitor
1000uF, ±20%, 50V, 105
06-10251-01 CPCYL1/D.640/LS.300/.031
C279
Bi-polarized Alu
Electrolytic Capacitor
10uF, ±20%, 50V, 105
06-10051-11 CPCYL1/D.200/LS.200/.031
C281 ALU Electrolytic Capacitor
4.7uF/50V, ±20%, 105
06-47951-05 CPCYL/D.200/LS.200/.031
C290 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C291 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
JUMPER
R2G1 Link L=5mm 21-06500-00 AX/.200X.080/.031
RL215 Link L=10mm 21-06101-00 AX/.400X.100/.031
W201 Link L=12.5mm 21-06121-01 AX/.500X.100/.031
W202 Link L=12.5mm 21-06121-01 AX/.500X.100/.031
W203 Link L=12.5mm 21-06121-01 AX/.500X.100/.031
W204 Link L=12.5mm 21-06121-01 AX/.500X.100/.031
W205 Link L=12.5mm 21-06121-01 AX/.500X.100/.031
W206 Link L=12.5mm 21-06121-01 AX/.500X.100/.031
BUS201 BUSBAR HS40-C375_B12V1-M025 69-124001-0
INDUCTOR
L201 Inductor 0.7uH, horizontal type 08-01079-01 RAD/.850X.450/LS.700/.059
L202 Inductor 0.7uH, horizontal type 08-01079-01 RAD/.850X.450/LS.700/.059
RELAY
RL201 RELAYS JRC-27F/012-S(555) 12-02101-02 RELAY_11
RL202 RELAYS JRC-27F/012-S(555) 12-02101-02 RELAY_11
RL203 RELAYS JRC-27F/012-S(555) 12-02101-02 RELAY_11
RL204 RELAYS JRC-27F/012-S(555) 12-02101-02 RELAY_11
RL205 RELAYS JRC-27F/012-S(555) 12-02101-02 RELAY_11
RL206 RELAYS JRC-27F/012-S(555) 12-02101-02 RELAY_11
RL207 RELAYS JRC-27F/012-S(555) 12-02101-02 RELAY_11
RL208 RELAYS JRC-27F/012-S(555) 12-02101-02 RELAY_11
RL209 RELAYS JRC-27F/012-S(555) 12-02101-02 RELAY_11
- 38 -
ELECTRICAL PARTS LIST
