NAD 375BEE C - Page 39

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
RL210 RELAYS JRC-27F/012-S(555) 12-02101-02 RELAY_11
RL211 RELAYS JQX-115F/036/1HS1 A12-03101-04 RELAY_1
RL212 RELAYS JQX-115F/036/1HS1 A12-03101-04 RELAY_1
RL213 RELAYS JQX-115F/036/1HS1 A12-03101-04 RELAY_1
RL214 RELAYS JQX-115F/036/1HS1 A12-03101-04 RELAY_1
POT
RV201 Stereo POT 1kΩB, RV142B-20-25A-B1K 09-02102-00 VRES20
CONNECTOR
J201 HEADPHONE SOCKET CKX-3.5-20A / LJE0366DS-5 17-07001-07
J202
DUAL 3.5 HEADPHONE
SOCKET
SCJ351P00YS0B00 J17-02002-02
RCA201 RCA 6RCA, AV6-8.4-13 17-01006-00 RCA6A
RCA202 RCA 6RCA, AV6-8.4-13 17-01006-00 RCA6A
RCA203 RCA 6RCA, AV6-8.4-13 17-01006-00 RCA6A
RCA204 RCA 6RCA, AV6-8.4-13 17-01006-00 RCA6A
P201B HOUSING 5PIN2.54-C 13-22505-00 BLKCON.100/VH/TM1SQS/W.300/5
P202B HOUSING 11PIN2.54-C 13-22511-01 BLKCON.100/VH/TM1SQS/W .300/11
P203A W IRE
UL2547#26AW G &
UL2547#24AW G, 8PIN
14-37508-00 BLKCON.100/VH/TM1SQ/W.200/8
P204B HOUSING 3PIN2.54-C 13-22503-00 BLKCON.100/VH/TM1SQ/W .200/3
P205B CONNECTOR CON2X10 MALE 13-22520-05 BLKCON.100/VH/TM2OE/W .200/20
P206B HOUSING 5PIN3.96-C 13-23905-00 BLKCON.156/VH/TM1SQB/W.355/5
P207B HOUSING 5PIN3.96-C 13-23905-00 BLKCON.156/VH/TM1SQB/W.355/5
P208B HOUSING 3PIN2.54-C 13-22503-00 BLKCON.100/VH/TM1SQ/W.200/3
P209A W IRE
UL1015#18AW G,
yellow/black/black/blue/red,
One terminal:VH-5Y, another
terminalSDN-5Y, L=150mm
14-37505-01
P210A W IRE
UL1015#18AW G,
yellow/black/black/blue/red,
One terminal:VH-5Y, another
terminalSDN-5Y, L=180mm
14-37505-02
P211A W IRE
UL2468#24AW G, One
terminal:XHB-11Y, another
terminalSCN-11Y, L=130mm
14-37511-00 BLKCON.100/VH/TM1SQS/W.200/11
P212A W IRE
UL2468#24AW G, One
terminal:XHB-11Y, another
terminalSCN-11Y, L=130mm
14-37511-00 BLKCON.100/VH/TM1SQS/W.200/11
P213B FPC
CNT-FPC125-12-TS, 1.25mm,
12pin
13-21212-01
P214B FPC
CNT-FPC125-12-TS, 1.25mm,
12pin
13-21212-01
P215B HOUSING 3PIN2.54-C 13-22503-00 BLKCON.100/VH/TM1SQ/W.200/3
To Binding Post
Board
WIRE
UL1015#16AW G, L=100mm,
6PIN
14-37506-01
G2G1 Ground Solder Tap GND-8 32-28042-00
SWITCH
S201 SWITCH SSSU122NA1 J11-05202-10 SLIDESWITCHES/SSSU141500
S202 SWITCH SSSU122NA1 J11-05202-10 SLIDESWITCHES/SSSU141500
P/N 01-37503-00 PCB3 BOARD (TONE)
DIODE
D301 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
TRANSISTOR
Q301 Transistor 2SB647-D 31-00647-01 TO-92
Q302 Transistor 2SD667-D 31-00667-01 TO-92
Q303 Transistor 2SB647-D 31-00647-01 TO-92
- 39 -
ELECTRICAL PARTS LIST
