NAD 375BEE C - Page 40

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
Q304 Transistor 2SD667-D 31-00667-01 TO-92
RESISTOR
R301 Metal Film Resistor 75KΩ, 1/6W , ±5% 07-20753-50 AX/.200X.080/.031
R302 Metal Film Resistor 75KΩ, 1/6W , ±5% 07-20753-50 AX/.200X.080/.031
R303 Chip Resistor 47Ω, ±5%,0805 07-90470-01 SM/R_0805
R304 Chip Resistor 47Ω, ±5%,0805 07-90470-01 SM/R_0805
R305 Metal Film Resistor 3.3KΩ, 1/6W , ±1% 07-23301-50 AX/.200X.080/.031
R306 Metal Film Resistor 3.3KΩ, 1/6W , ±1% 07-23301-50 AX/.200X.080/.031
R307 Metal Film Resistor 732Ω, 1/6W, ±1% 07-27320-50 AX/.200X.080/.031
R308 Metal Film Resistor 732Ω, 1/6W, ±1% 07-27320-50 AX/.200X.080/.031
R309 Metal Film Resistor 390Ω, 1/6W, ±1% 07-23900-50 AX/.200X.080/.031
R310 Metal Film Resistor 390Ω, 1/6W, ±1% 07-23900-50 AX/.200X.080/.031
R311 Metal Film Resistor 180Ω, 1/6W, ±1% 07-21800-50 AX/.200X.080/.031
R312 Metal Film Resistor 180Ω, 1/6W, ±1% 07-21800-50 AX/.200X.080/.031
R313 Metal Film Resistor 51KΩ, 1/6W , ±5% 07-20513-50 AX/.200X.080/.031
R314 Metal Film Resistor 51KΩ, 1/6W , ±5% 07-20513-50 AX/.200X.080/.031
R317 Metal Film Resistor 1.5KΩ, 1/6W , ±1% 07-21501-50 AX/.200X.080/.031
R318 Metal Film Resistor 1.5KΩ, 1/6W , ±1% 07-21501-50 AX/.200X.080/.031
R319 Metal Film Resistor 390Ω, 1/6W, ±1% 07-23900-50 AX/.200X.080/.031
R320 Metal Film Resistor 390Ω, 1/6W, ±1% 07-23900-50 AX/.200X.080/.031
R321 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R322 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R323 Metal Film Resistor 2K2Ω, 1/6W , 5% 07-20222-50 AX/.200X.080/.031
R324 Metal Film Resistor 2K2Ω, 1/6W , 5% 07-20222-50 AX/.200X.080/.031
R325 Metal Film Resistor 2K2Ω, 1/6W , 5% 07-20222-50 AX/.200X.080/.031
R326 Metal Film Resistor 2K2Ω, 1/6W , 5% 07-20222-50 AX/.200X.080/.031
R327 Metal Film Resistor 2K2Ω, 1/6W , 5% 07-20222-50 AX/.200X.080/.031
R328 Metal Film Resistor 2K2Ω, 1/6W , 5% 07-20222-50 AX/.200X.080/.031
R329 Metal Film Resistor 47Ω, 1/6W, ±5% 07-20470-50 AX/.200X.080/.031
R333 Chip Resistor 47Ω, ±5%,0805 07-90470-01 SM/R_0805
R334 Chip Resistor 47Ω, ±5%,0805 07-90470-01 SM/R_0805
CAPACTIOR
C301 ALU Electrolytic Capacitor
100uF/16V, 20%, 105
06-10111-07 CPCYL1/D.300/LS.200/.031
C302 ALU Electrolytic Capacitor
100uF/16V, 20%, 105
06-10111-07 CPCYL1/D.300/LS.200/.031
C303 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C304 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C305 Polyester capacitor 22nF, ±5%, 63V 25-22361-04 RAD/CAP/.400X.150/LS.300/.031
C306 Polyester capacitor 22nF, ±5%, 63V 25-22361-04 RAD/CAP/.400X.150/LS.300/.031
C307 Polyester capacitor 100nF, ±5%, 63V 25-10461-04 RAD/CAP/.400X.150/LS.300/.031
C308 Polyester capacitor 100nF, ±5%, 63V 25-10461-04 RAD/CAP/.400X.150/LS.300/.031
C309 Polyester capacitor 220nF, ±5%, 63V 25-22461-02 RAD/CAP/.300X.250/LS.200/.031
C310 Polyester capacitor 220nF, ±5%, 63V 25-22461-02 RAD/CAP/.300X.250/LS.200/.031
C311 Polyester capacitor 1uF, ±5%, 63V 25-10561-00 RAD/CAP/.300X.250/LS.200/.031
C312 Polyester capacitor 1uF, ±5%, 63V 25-10561-00 RAD/CAP/.300X.250/LS.200/.031
C313 Ceramic Capacitor 220pF, ±10%, 1KV 05-22113-01 CPAX/.200X.100/.031
C314 Ceramic Capacitor 220pF, ±10%, 1KV 05-22113-01 CPAX/.200X.100/.031
C317 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C318 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C319 ALU Electrolytic Capacitor
220uF, ±20%, 25V, 105
06-22121-03 CPCYL1/D.200/LS.200/.031
C320 ALU Electrolytic Capacitor
220uF, ±20%, 25V, 105
06-22121-03 CPCYL1/D.200/LS.200/.031
C321 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C322 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C323 ALU Electrolytic Capacitor
10uF, ±20%, 50V, 105
06-10021-04 CPCYL1/D.300/LS.200/.031
- 40 -
ELECTRICAL PARTS LIST
