NAD 375BEE C - Page 41

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
C324 ALU Electrolytic Capacitor
10uF, ±20%, 50V, 105
06-10021-04 CPCYL1/D.300/LS.200/.031
C325 ALU Electrolytic Capacitor
10uF, ±20%, 50V, 105
06-10021-04 CPCYL1/D.300/LS.200/.031
C326 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C327
Bi-polarized Alu
Electrolytic Capacitor
4.7uF,50V,±20%, 85
06-47951-04 CPCYL1/D.200/LS.200/.031
C329 Ceramic Capacitor 470pF, ±5%, 1KV 05-47113-02 CPAX/.200X.100/.031
C330 Ceramic Capacitor 470pF, ±5%, 1KV 05-47113-02 CPAX/.200X.100/.031
JUMPER
W301 Link L=7.5mm 21-06750-00
POT
RV301 POT RD163121A174-10KA×2 J09-01103-14 VPOT_4
RV302 POT RD163121A174-10KA×2 J09-01103-14 VPOT_4
RV303 POT RK16812MGA10(20KBX2) J09-01203-05 VPOT_5
RV304 POT RD163121A020 20KMN J09-01203-06 VPOT_4
RV305 POT 10KΩ 09-02103-00 VRES21
RV306 POT 10KΩ 09-02103-00 VRES21
RV307 POT 100Ω 09-02101-00 VRES21
RV308 POT 100Ω 09-02101-00 VRES21
RELAY
RL301 RELAYS JRC-27F/005-S(555) 12-02202-03 RELAY_11
CONNECTOR
P302B HOUSING 10PIN2.54-C 13-22510-00 BLKCON.100/VH/TM1SQS/W .300/10
P301A W IRE
UL1007#24AW G, L=40mm,
11PIN
14-37511-02 BLKCON.100/VH/TM1SQ/W.200/11
P300 to main
board
WIRE
UL1015#18AW G , L=160mm,
1PIN
14-37501-08
AH P/
N


01-37504-10 C P/
N

01-37504-20 PCB4 BOARD (STANDBY)
DIODE
D401
Super Fast Recovery
Rectifier Diode
FR107 33-20107-00 DAX/.400X.100/.039
D402 Schottky Barrier Rectifier 1N5822 33-25822-00 DAX/.300X.200/.059
D403 Zener Diode 4.7V, 1/2W, ±2% 33-14709-05 DAX/.300X.080/.031
D404 Switch Diode 1N5819 33-25819-00 DAX/.400X.100/.039
D405 RECTIFY DIODES 1N4007 33-24007-00 DAX/.400X.100/.039
D406 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D407 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D408 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D409 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
BRIDGE
BR401 Rectifier Bridge DB105 33-30162-00 DIP4
IC
IC401 Power controller IC TNY274PN 03-00274-00 DIP-8C
IC402 RAGULATOR L7805CT 03-07805-00 TO220AB/123
PC401 Photocoupler PC817A 03-00817-01 DIP4
RESISTOR
R401 Metal Oxide Film Resistor 68KΩ, 1W, ±5% 07-30683-21 AX/.600X.125/.039
R402 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R403 Metal Film Resistor
510, 1/6W, 5%
07-20511-50 AX/.200X.080/.031
R404 Metal Film Resistor 150Ω, 1/6W, ±5% 07-20151-50 AX/.200X.080/.031
CAPACTIOR
C401
Interfernece Suppression
Cap
0.1uF/275V, ±10% A25-10422-07 RAD/CAP/.400X.200/LS.400/.031
- 41 -
ELECTRICAL PARTS LIST
