NAD 375BEE C - Page 42

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
C402 ALU Electrolytic Capacitor
10uF,400V,±20%, 105
06-10042-00 CPCYL1/D.400/LS.200/.031
C403 X Capacitor 10nF/275V, ±10% A25-10322-05 RAD/CAP/.400X.200/LS.400/.031
C404 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C405 Y Capacitor 1nF, Y Type A05-10242-00 RAD/CAP/.400X.200/LS.400/.031
C406 ALU Electrolytic Capacitor
220uF, 16V, ±20%, 105
06-22111-21 CPCYL1/D.300/LS.200/.031
C407 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C408 ALU Electrolytic Capacitor
220uF, 16V, ±20%, 105
06-22111-21 CPCYL1/D.300/LS.200/.031
C409 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C410 ALU Electrolytic Capacitor
220uF, 10V, ±20%, 105
06-22111-20 CPCYL1/D.300/LS.200/.031
JUMPER
W401(AH) Link(φ1.0) 7.5mm 21-10750-00 7.5mm
W402(AH) Link(φ1.0) 7.5mm 21-10750-00 7.5mm
W403(C) Link(φ1.0) 7.5mm 21-10750-00 7.5mm
W404 Link(φ1.0) 10mm 21-10101-00 10mm
W405 Link(φ1.0) 10mm 21-10101-00 10mm
INDUCTOR
L401 INDUCTOR 10uH 19-35980-00 AX/.400X.100/.031
TRANSFORMER
TR402 Transformer EE16 9V 5W A18-37516-00 TRANS_2
RELAY
RL401 RELAYS DH1U5VDC TV-8 DH5D1-O A12-02101-01
FUSE
F401 FUSE T1AL/250V A20-12102-00
FUSE HOLDER
F401 FUSE HOLDER LS-PTF-78 (CQ-200C) A20-20000-06 RAD/.1000X.400/LS.850/.066
CONNECTOR
J401 JACK HS4-CI9120-B009V1-M032 32-26304-00
J402 JACK KY187 32-24804-00
P402B HOUSING 6PIN2.54-C 13-22506-00 BLKCON.100/VH/TM1SQS/W.300/6
P403B HOUSING 2PIN3.96-C 13-23902-00 BLKCON.156/VH/TM1SQB/W.355/2
P404B HOUSING 4PIN7.92-C 13-23907-01 BLKCON.156/VH/TM1SQS/W.355/7
P401 to AC
OUTLET(AH)
WIRE UL1672#16AWG , L=420mm A14-37501-03
P402 to AC
OUTLET(AH)
WIRE UL1672#16AWG , L=420mm A14-37501-04
P/
N


01-37505-00 PCB5 BOARD (DISPLAY)
DIODE
D501 RECTIFY DIODES 1N4007 33-24007-00 DAX/.400X.100/.039
D502 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D503 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D504 LED (three color)
φ5, Blue/Red/Amber Three
color BL-BUBJFB52C4V-1
33-50565-02
D505 LED BLUE φ3, BLUE, BL-BB52V1 33-50360-06 LED/D.225/LS.100/.039
D506 LED BLUE φ3, BLUE, BL-BB52V1 33-50360-06 LED/D.225/LS.100/.039
D507 LED BLUE φ3, BLUE, BL-SB3248 33-50360-07 LED/D.225/LS.100/.039
D508 LED BLUE φ3, BLUE, BL-SB3248 33-50360-07 LED/D.225/LS.100/.039
D509 LED (Dual Color) φ3,Blue/Blue,BL-BB5B5201-B 33-50366-00
D510 LED BLUE φ3, BLUE, BL-SB3248 33-50360-07 LED/D.225/LS.100/.039
D511 LED BLUE φ3, BLUE, BL-SB3248 33-50360-07 LED/D.225/LS.100/.039
D512 LED (Dual Color) φ3,Blue/Blue,BL-BB5B5201-B 33-50366-00
D513 LED BLUE φ3, BLUE, BL-SB3248 33-50360-07 LED/D.225/LS.100/.039
- 42 -
ELECTRICAL PARTS LIST
