NAD 375BEE C - Page 43

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
D514 LED BLUE φ3, BLUE, BL-SB3248 33-50360-07 LED/D.225/LS.100/.039
D515 LED BLUE φ3, BLUE, BL-SB3248 33-50360-07 LED/D.225/LS.100/.039
D516 LED BLUE φ3, BLUE, BL-SB3248 33-50360-07 LED/D.225/LS.100/.039
D517 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D518 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D532 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D533 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D534 Zener Diode 4.7V, 1/2W 33-14709-00 DAX/.300X.080/.031
D535 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D536 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D538 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D539 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D540 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D541 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D542 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D543 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D544 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D545 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D546 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D547 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D548 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D549 Switch Diode 1N4148 33-44148-00 DAX/.300X.080/.031
D550 RECTIFY DIODES 1N4007 33-24007-00 DAX/.400X.100/.039
TRANSISTOR
Q502 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q503 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q504 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q505 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q506 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q507 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q508 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q509 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q510 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q522 Digital Transistor DTA114ESA 31-00114-03 TO-92
Q523 Digital Transistor DTA114ESA 31-00114-03 TO-92
Q524 Digital Transistor DTA114ESA 31-00114-03 TO-92
Q525 Digital Transistor KRC102M-AT/P 31-00102-00 TO-92
Q528 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q529 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q530 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q531 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q532 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q533 Transistor 2SD667-D 31-00667-01 TO-92
Q534 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q535 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q536 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q537 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q538 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q539 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q540 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q541 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q542 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q543 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q544 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q545 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
- 43 -
ELECTRICAL PARTS LIST
