DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
Q546 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q547 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q548 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q549 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q550 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q551 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
IC
IC501
Enhanced RS-232 Line
Drivers/Receivers
SP232EEP 03-00232-00 DIP.100/16/W .300/L.775
IC502
Supervisory Circuits with
I2C Serial 2k-bit CMOS
EEPROM
CAT1021PI-42 03-01021-01 DIP.100/8/W.300/L.400
IC503 MICOM AT89S52-24PU 03-08952-20 DIP.100/40/W .600/L2.050
IC504 IR Sensor HS0038B4 03-00038-40
IC505 Shift Registers CD4094 03-04094-00 DIP.100/16/W.300/L.775
RESISTOR
R501 Metal Film Resistor 10KΩ, 1/6W , 5% 07-20103-50 AX/.200X.080/.031
R502 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R503 Metal Film Resistor 10KΩ, 1/6W , 5% 07-20103-50 AX/.200X.080/.031
R504 Metal Film Resistor 10KΩ, 1/6W , 5% 07-20103-50 AX/.200X.080/.031
R505 Metal Film Resistor 10KΩ, 1/6W , 5% 07-20103-50 AX/.200X.080/.031
R506 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R507 Metal Film Resistor 10KΩ, 1/6W , 5% 07-20103-50 AX/.200X.080/.031
R508 Metal Film Resistor 10KΩ, 1/6W , 5% 07-20103-50 AX/.200X.080/.031
R509 Metal Film Resistor 10KΩ, 1/6W , 5% 07-20103-50 AX/.200X.080/.031
R510 Resistor NET 1K, ±5%,8R9P,A102J 07-00102-00 SIP/TM/L.900/9
R511 Resistor NET 1K, ±5%,8R9P,A102J 07-00102-00 SIP/TM/L.900/9
R512 Metal Film Resistor 10KΩ, 1/6W , 5% 07-20103-50 AX/.200X.080/.031
R513 Metal Film Resistor
56, 1/6W, 5%
07-20560-50 AX/.200X.080/.031
R514 Metal Film Resistor
56, 1/6W, 5%
07-20560-50 AX/.200X.080/.031
R515 Metal Film Resistor
56, 1/6W, 5%
07-20560-50 AX/.200X.080/.031
R516 Metal Film Resistor
56, 1/6W, 5%
07-20560-50 AX/.200X.080/.031
R517 Metal Film Resistor
56, 1/6W, 5%
07-20560-50 AX/.200X.080/.031
R518 Metal Film Resistor
56, 1/6W, 5%
07-20560-50 AX/.200X.080/.031
R519 Metal Film Resistor
56, 1/6W, 5%
07-20560-50 AX/.200X.080/.031
R520 Metal Film Resistor 130Ω, 1/6W, ±5% 07-20131-50 AX/.200X.080/.031
R521 Metal Film Resistor 270Ω, 1/6W, ±1% 07-22700-50 AX/.200X.080/.031
R522 Metal Film Resistor 130Ω, 1/6W, ±5% 07-20131-50 AX/.200X.080/.031
R523 Metal Film Resistor 10KΩ, 1/6W , 5% 07-20103-50 AX/.200X.080/.031
R525 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
R526 Metal Film Resistor 4.7KΩ, 1/6W, ±5% 07-20472-50 AX/.200X.080/.031
R527 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R528 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R529 Metal Film Resistor
56, 1/6W, 5%
07-20560-50 AX/.200X.080/.031
R530 Metal Film Resistor
56, 1/6W, 5%
07-20560-50 AX/.200X.080/.031
R531 Metal Film Resistor
56, 1/6W, 5%
07-20560-50 AX/.200X.080/.031
R532 Metal Film Resistor
56, 1/6W, 5%
07-20560-50 AX/.200X.080/.031
R533 Metal Film Resistor
56, 1/6W, 5%
07-20560-50 AX/.200X.080/.031
R534 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R535 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R536 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R537 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R538 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R539 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R540 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R541 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R542 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
- 44 -
ELECTRICAL PARTS LIST
