NAD 375BEE C - Page 45

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
R543 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R544 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R545 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R546 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R547 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R548 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R549 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R550 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R552 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R553 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R554 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R555 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R556 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R557 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R558 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R559 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R560 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R561 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R562 Metal Film Resistor 4.7KΩ, 1/6W, ±5% 07-20472-50 AX/.200X.080/.031
R563 Metal Film Resistor 4.7KΩ, 1/6W, ±5% 07-20472-50 AX/.200X.080/.031
R564 Metal Film Resistor 4.7KΩ, 1/6W, ±5% 07-20472-50 AX/.200X.080/.031
R565 Metal Film Resistor 10Ω, 1/6W, 5% 07-20100-50 AX/.200X.080/.031
R566 Metal Film Resistor 10Ω, 1/6W, 5% 07-20100-50 AX/.200X.080/.031
R567 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-50 AX/.200X.080/.031
R568 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-50 AX/.200X.080/.031
R569 Metal Film Resistor 2K2Ω, 1/6W , 5% 07-20222-50 AX/.200X.080/.031
R570 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R571 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
R572 Metal Film Resistor 4.7KΩ, 1/6W , ±5% 07-20472-50 AX/.200X.080/.031
CAPACTIOR
C501 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C502 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C503 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C504 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C505 Ceramic Capacitor 22pF, ±5%, 1KV 05-22013-02 CPAX/.200X.100/.031
C506 Ceramic Capacitor 22pF, ±5%, 1KV 05-22013-02 CPAX/.200X.100/.031
C507 Polyester capacitor 10nF, ±5%, 63V 25-10361-02 RAD/CAP/.300X.150/LS.200/.031
C508 ALU Electrolytic Capacitor
100uF/16V, 20%, 105
06-10111-07 CPCYL1/D.300/LS.200/.031
C509 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C510 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C511 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C512 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C513 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C514 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
C517 ALU Electrolytic Capacitor
1000uF,10V,±20%, 105
06-10211-05 CPCYL/D.400/LS.200/.031
C518 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C519 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C520 ALU Electrolytic Capacitor
10uF/50V, ±20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C521 Polyester capacitor 100nF, ±5%, 63V 25-10461-07 RAD/CAP/.300X.150/LS.200/.031
JUMPER
R551 Link L=5mm 21-06500-00 AX/.200X.080/.031
- 45 -
ELECTRICAL PARTS LIST
