NAD 375BEE C - Page 46

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
CRYSTAL
X501 Crystal
11.0592MHz,CL=15pF,HC-
49U/S
04-11102-00 CRYSTAL/.450X.200/LS.200/.031
CONNECTOR
X501 Crystal Washer (QW-3) 75-040001-0
J501 Phone Jack SCJ340R0GBS0B00 J17-02001-02
FOR IC503 IC Socket DIP40 13-22540-00 DIP40
P501A W IRE
UL2468#24AW G,L=240mm,
10PIN
14-37510-01 BLKCON.100/VH/TM1SQ/W.200/10
P502A W IRE
UL2468#24AW G,L=70mm,
6PIN
14-37506-00 BLKCON.100/VH/TM1SQ/W.200/6
P503A W IRE
UL2651#28AW G, L=580mm,
20PIN
14-37520-00 BLKCON.100/VH/TM2OE/W.200/20
P504A W IRE
UL1007#24AW G &
UL1691#24AW G,
L=790mm,5PIN
14-37505-00 BLKCON.100/VH/TM1SQ/W.200/5
G501 Ground Solder Tap GND-8 32-28042-00
SWITCH
S501 Tact Switch IT-1102A-1160 11-04101-05
S502 Tact Switch IT-1102A-1160 11-04101-05
S503 Tact Switch IT-1102A-1160 11-04101-05
S504 Tact Switch IT-1102A-1160 11-04101-05
S505 Tact Switch IT-1102A-1160 11-04101-05
S506 Tact Switch IT-1102A-1160 11-04101-05
S507 Tact Switch IT-1102A-1160 11-04101-05
S508 Tact Switch IT-1102A-1160 11-04101-05
S509 Tact Switch IT-1102A-1160 11-04101-05
S510 Tact Switch IT-1102A-1160 11-04101-05
S511 Tact Switch IT-1102A-1160 11-04101-05
P/N 01-37506-10 & 20 PCB6 BOARD (HS OPAMP STEREO)
TRANSISTOR
Q601 MOSFET 2SK209 J31-00209-00 SM/SC59_SDG
Q602 MOSFET 2SK209 J31-00209-00 SM/SC59_SDG
Q603 Transistor 2SA1312 J31-01312-00 SM/SC59_BEC
Q604 Transistor 2SA1312 J31-01312-00 SM/SC59_BEC
Q605 Transistor 2SC3324 J31-03324-00 SM/SC59_BEC
Q606 Transistor 2SC3324 J31-03324-00 SM/SC59_BEC
Q607 Transistor 2SC3324 J31-03324-00 SM/SC59_BEC
Q608 Transistor 2SC3324 J31-03324-00 SM/SC59_BEC
Q609 Transistor 2SC2983 J31-02983-00 TO126/90/ECB
Q610 Transistor 2SC2983 J31-02983-00 TO126/90/ECB
Q611 Transistor 2SA1225 J31-01225-00 TO126/90/ECB
Q612 Transistor 2SA1225 J31-01225-00 TO126/90/ECB
Q613 Transistor 2SC3324 J31-03324-00 SM/SC59_BEC
Q614 Transistor 2SC3324 J31-03324-00 SM/SC59_BEC
RESISTOR
R601 Chip Resistor 1megΩ ,1/8W,±5% 07-90105-00 SM/R_0603
R602 Chip Resistor 1megΩ ,1/8W,±5% 07-90105-00 SM/R_0603
R603 Chip Resistor 220Ω ,1/8W,±5% 07-90221-00 SM/R_0603
R604 Chip Resistor 220Ω ,1/8W,±5% 07-90221-00 SM/R_0603
R605 Chip Resistor 1KΩ ,1/8W,±5% 07-90102-00 SM/R_0603
R606 Chip Resistor 1KΩ ,1/8W,±5% 07-90102-00 SM/R_0603
R607 Chip Resistor 1KΩ ,1/8W,±5% 07-90102-00 SM/R_0603
R608 Chip Resistor 1KΩ ,1/8W,±5% 07-90102-00 SM/R_0603
R609 Chip Resistor 1.5KΩ ,1/8W ,±5% 07-90152-00 SM/R_0603
R610 Chip Resistor 1.5KΩ ,1/8W ,±5% 07-90152-00 SM/R_0603
- 46 -
ELECTRICAL PARTS LIST
