DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
R611 Chip Resistor 1KΩ ,1/8W ,±5% 07-90102-00 SM/R_0603
R612 Chip Resistor 1KΩ ,1/8W ,±5% 07-90102-00 SM/R_0603
R613 Chip Resistor 18KΩ ,1/8W,±5% 07-90183-00 SM/R_0603
R614 Chip Resistor 18KΩ ,1/8W,±5% 07-90183-00 SM/R_0603
R615 Chip Resistor 10Ω ,1/8W,±5% 07-90100-00 SM/R_0603
R616 Chip Resistor 10Ω ,1/8W,±5% 07-90100-00 SM/R_0603
R617 Chip Resistor 10Ω ,1/8W,±5% 07-90100-00 SM/R_0603
R618 Chip Resistor 10Ω ,1/8W,±5% 07-90100-00 SM/R_0603
R619 Chip Resistor 430Ω ,1/8W,±1% 07-94300-00 SM/R_0603
R620 Chip Resistor 430Ω ,1/8W,±1% 07-94300-00 SM/R_0603
R621 Chip Resistor 487Ω ,1/8W,±1% 07-94870-00 SM/R_0603
R622 Chip Resistor 487Ω ,1/8W,±1% 07-94870-00 SM/R_0603
R623 Chip Resistor 8.2KΩ ,1/8W,±1% 07-98201-00 SM/R_0603
R625 Chip Resistor 150KΩ ,1/10W ,±5% 07-90154-00 SM/R_0603
R626 Chip Resistor 150KΩ ,1/10W ,±5% 07-90154-00 SM/R_0603
R627 Chip Resistor 100KΩ ,1/10W ,±5% 07-90104-00 SM/R_0603
R628 Chip Resistor 100KΩ ,1/10W ,±5% 07-90104-00 SM/R_0603
CAPACTIOR
C601 Ceramic Chip Capacitor 22pF,50V,NPO 26-22051-00 SM/C_0603
C602 Ceramic Chip Capacitor 22pF,50V,NPO 26-22051-00 SM/C_0603
C603 Ceramic Chip Capacitor 47pF,50V,NPO 26-47051-00 SM/C_0603
C604 Ceramic Chip Capacitor 47pF,50V,NPO 26-47051-00 SM/C_0603
C605 Ceramic Chip Capacitor 1nF,50V,NPO 26-10251-10 SM/C_0603
C606 Ceramic Chip Capacitor 1nF,50V,NPO 26-10251-10 SM/C_0603
C607 Ceramic Chip Capacitor 100nF,50V,X7R 26-10451-10 SM/C_0603
C608 Ceramic Chip Capacitor 100nF,50V,X7R 26-10451-10 SM/C_0603
C609 Ceramic Chip Capacitor 100nF,50V,X7R 26-10451-10 SM/C_0603
C610 Ceramic Chip Capacitor 100nF,50V,X7R 26-10451-10 SM/C_0603
C611 Ceramic Chip Capacitor 47pF,50V,NPO 26-47051-00 SM/C_0603
C613 Ceramic Chip Capacitor 1uF,25V,Y5V 26-10521-00 SM/C_0603
C614 Ceramic Chip Capacitor 1uF,25V,Y5V 26-10521-00 SM/C_0603
C617 Ceramic Chip Capacitor 220pF,50V,NPO 26-22151-00 SM/C_0603
C618 Ceramic Chip Capacitor 220pF,50V,NPO 26-22151-00 SM/C_0603
CONNECTOR
P601A CONNECTOR 10PIN2.54 RIGHT ANGLE 13-12510-01 BLKCON.100/VH/TM1SQ/W.200/10
P/N 01-37507-00 PCB7 BOARD (RS232)
RESISTOR
R701 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-50 AX/.200X.080/.031
CONNECTOR
J701 DB9 Connector FEMALE DB9 FEMALE 17-08009-00 DSUB9M-RA-RS
P701A W IRE
UL2468#24AW G,L=80mm,
3PIN
14-37503-00 BLKCON.100/VH/TM1SQ/W.200/3
P702B HOUSING 3PIN2.54C 13-22503-00 BLKCON.100/VH/TM1SQ/W.200/3
P/N 01-37508-00 PCB8 BOARD (HEADPHONE)
CONNECTOR
J801 Phone Jack 2P2.54-A150B 1569-26AWG 17-02001-00
P801A W IRE
UL2468#24AW G,L=170mm,
3PIN
14-37503-01 BLKCON.100/VH/TM1SQ/W.200/3
P/N 01-37512-00 PCB9 BOARD (BP BOARD)
CONNECTOR
P901B CONNECTOR VH 3.96-6A 13-23906-00
Assembly Parts
FUSE
FUSE
T10AL/250VAH
A20-12103-00
- 47 -
ELECTRICAL PARTS LIST
