27
PSU BOARD
PCB ASSEMBLY *AH 50-903-0326-90 C326 AH PSU ASSY
PCB ASSEMBLY *C,CT 50-904-0326-90 C326 C/CT PSU ASSY
ICS
U601 01-003-0104-90 IC TINYSWITCH-III TNY274PN DIP-8C
U602 01-006-0033-90 IC FOD817C300 OPTOCOUPLER
FAIRCHILD (RoHS)
RESISTORS
R627 02-001-0451-90 RES CONDUCTIVE PATH 3.9M OHM
1/2W 5% RNV1/2 395J (RoHS)
R603 R626 02-005-0074-90 MPR-RES 0.05 OHM 5W 5% E TYPE
14x5x18mm (RoHS)
R615 02-010-0039-90 RES MO 100K OHM 5% 1W AXIAL(RoHS)
CAPACITORS
C606 03-002-0084-90 E CAP 2200uF/50V ±20% 85*C 16X35mm
P=7.5 GS (RoHS)
C621 03-002-0148-90 CAP ELEC SS 4.7uF 50V 20% 85C RAD
HEIGHT=7mm MAX (RoHS)
C601-602 03-002-0187-90 E CAP 15000uF/50V ±20% 85*C 35x50mm
P=10 LP (RoHS)
C605 03-002-0188-90 E CAP 3300uF/50V ±20% 85*C 18x35mm
P=7.5 GS (RoHS)
C612 03-002-0189-90 E CAP 10uF/400V ±20% 105*C 10x20mm
P=5.0 SK (RoHS)
C608-609 03-002-0195-90 E CAP 330uF 16V 20% 105*C 8x12mm
LOW IMPEDANCE GL KSC (RoHS)
C603-604 03-004-0085-90 MER CAP 0.01uF/630V/103K 10% MTC
P=10 TC
C617 03-004-0139-90 MEX CAP 0.22uF/275VAC X2 UL/CSA/VDE
(RoHS)
C611 03-004-0144-90 FILM CAP 0.01uF 1000V 10% P=15 PPN
MATRONIC (RoHS)
C616 C618 03-007-0022-90 CER CAP 4700pF/250VAC ±20% Y5V RAD
JY12F472MK02 Y2 UL/CSA/VDE (RoHS)
C610 03-007-0023-90 HC CER CAP 2200pF/440VAC ±20% Y1/X1
JN UL/CSA/VDE (RoHS)
DIODES
D601-602 04-001-0046-90 Diode Rect 12A/600V TO-220 TYN612
(RoHS) (ST)
D607 04-001-0053-90 DIODE FR107 1A/1000V DO-41 FAST
RECOVERY (RoHS)
D608 04-002-0068-90 SCHOTTKY DIODE SR540 5A/40V DO-27
(RoHS)
D603-604 04-005-0027-90 DIODE BRI 8A/200V KBU8D (DC) (RoHS)
D605 04-005-0028-90 DIODE BRI 1A/400V DB104 (DC) (RoHS)
D606 04-005-0029-90 DIODE BRI 1A/600V DB105 (DC) (RoHS)
COIL
L602 07-002-0161-90 IND COIL RADIAL 10uH 20% 22.5T
RC5X25-100M EASE HOUSE(RoHS)
RELAY
RL601 07-005-0063-90 RELAY MINIATURE 5VDC/10A 1P1T
TV-5 ME-7-005-HL MASSUSE (RoHS)
