28
CHOKE
L601 07-008-0002-90 LINE CHOKE 4 PIN 250VAC UL BASE
(RoHS)
TRANSFORMER
T601 10-005-0295-90 TRANSFORMER SWITCHING EE16
C326
FUSE
F601 *AH 20-001-0086-90 FUSE 3.15A 250V TIME LAG LBC
5x20mm TSD UL/CSA/VDE/SEMKO
(RoHS)
F601 *C/CT 20-001-0076-90 FUSE 1.6A 250V TIME LAG LBC
5X20mm TSD UL/CSA/VDE/SEMKO
(RoHS)
SMD RESISTORS
R605 R607 R610 R612 02-007-0042-90 SMD RES 1K OHM 0603 5% (RoHS)
R613 R623 02-007-0139-90 SMD RES 4.7K OHM 0603 5% (RoHS)
R609 R606 R616 02-007-0141-90 SMD RES 100 OHM 0603 5% (RoHS)
R608 R611 02-007-0145-90 SMD RES 22K OHM 0603 5% (RoHS)
R601 R604 02-007-0291-90 RES SMD 150 OHM 5% 1/16W 0603
TAPE (RoHS)
R617 02-007-0372-90 RES SMD 220 OHM 5% 1/16W 0603
TAPE(RoHS)
R624-625 02-007-0392-90 RES SMD 2K OHM 5% 1/16W 0603
TAPE (RoHS)
R602 02-007-0448-90 RES SMD 820K OHM 5% 1/16W 0603
TAPE (RoHS)
SMD CAPACITORS
C607 C615 03-009-0075-90 CAP CER SMD 0.1uF 50V 20% Y5V 0603
TAPE
C619-620 03-009-0111-90 CAP CER SMD 100pF 50V 10% X7R
0603 TAPE (RoHS)
SMD DIODES
D615 D623 D624 04-006-0019-90 DIODE RECT 1A/400V DO-214AC SMD
GS1G M4 GS1G (DC) (RoHS)
D621 D622 Replaced with R628 See schematic 1Kohm 1W leaded resistor
(RoHS)
D609 04-007-0063-90 DIODE ZENER SMD 4.7V 500mW 5%
SOD123 MMSZ5230B (RoHS) (DC)
SMD TRANSISTORS
Q605-606 Q608-609 05-004-0018-90 SMD Transistor MMBT5551LT1G NPN
SOT-23 (ON) (RoHS)
Q601-604 05-004-0019-90 SMD Transistor MMBT5401LT1G PNP
SOT-23 (ON) (RoHS)
JUMPERS
JMP2 JMP4-5 JMP19 17-016-0077-90 Jumper wire Dia. 0.5mm L=52.0mm
(RoHS)
JMP1 JMP3 JMP6-18 JMP20 17-016-0080-90 Jumper Wire Dia. 0.6mm For L Smaller
than 14mm Roll (RoHS)
VOLUME BOARD
PCB ASSEMBLY 50-914-0326-90 C326 AH VOLUME ASSY
