30
JUMPERS
JMP209-210 JMP212-213 JMP222-223 17-016-0077-90 Jumper wire Dia. 0.5mm L=52.0mm (RoHS)
JMP226-228
JMP144 JMP189 JMP211 JMP214-220 17-016-0080-90 Jumper Wire Dia. 0.6mm For L Smaller than
JMP224-226 14mm Roll (RoHS)
J1/MOTOR J2/MOTOR
KEYBOARD
PCB ASSEMBLY 50-922-0326-90 C326 KEYBOARD ASSY
CAPACITORS
C514 C521 03-002-0010-90 E CAP 47uF/16V ±20% 85*C 5x11mm P=2.0
GS (RoHS)
C524 03-002-0138-90 CAP ELEC SS 0.1uF 50V 20% 85C RAD
HEIGHT=7mm (RoHS)
IR RECEIVER
D515 04-009-0003-90 IR RX 37.9kHz SHIELD RT
FM-6038TM2-5AN (ROHS)
TACT SWITCH
S501-509 11-007-0061-90 SW TACT 1P1T 50mA/12V VER H=5mm
LUG FUNG (RoHS)
LEDS
D516 12-006-0125-90 LED RED-ORN-BLU CIRCULAR 5X8.7MM
BL-BUBJFB52C4V-1 COMMON ANODE
(RoHS)
D501-508, D517 12-006-0064-90 LED BLUE DIFFUSED ROUND D3x5.2mm
L-7104PBD (RoHS)
CRYSTAL
X501 14-002-0023-90 Crystal 20.000MHz 30ppm 32pF HC-49/S
01-CR1-02-20M000-32-3030 (RoHS)
SMD ICS
U503 0130300104820- Programmed MCU 8 BITS 8K ROM 512
900100 BYTES'RAM TQFP ATMega48-20
U501-502 01-012-0065-90 IC Logic 8-Stage Shift-And-Store Bus
Register SMD SO16 HEF4094BT
<HEF4094BT,653 PHI> (PHILIPS) (RoHS)
SMD RESISTORS
R530 R544 R545 02-007-0034-90 SMD RES 1.5K OHM 0805 5%
2.0X1.25X0.55 (RoHS)
R517-519 02-007-0042-90 SMD RES 1K OHM 0603 5% (RoHS)
R501-516 R540-541 02-007-0139-90 SMD RES 4.7K OHM 0603 5% (RoHS)
R532 02-007-0148-90 SMD RES 10K OHM 0603 5% (RoHS)
R524 R526 R528 R533-536 R542 02-007-0157-90 SMD RES 10K OHM 0603 1% (RoHS)
R523 02-007-0288-90 RES SMD 0 OHM 5% 1/16W 0603 TAPE
(RoHS)
R520-522 R527 02-007-0292-90 RES SMD 2.2K OHM 1% 1/16W 0603 TAPE
(RoHS)
R539 02-007-0299-90 RES SMD 10M OHM +/-5% 1/16W 0603
TAPE (RoHS)
R525 02-007-0368-90 RES SMD 1.5K OHM 5% 1/16W 0603
TAPE(RoHS)
R543 02-007-0581-90 RES SMD 1K OHM 5% 1W 2512 TAPE
(RoHS)
