NAD C 326BEE - Page 31

31
SMD CAPACITORS
C511-513 C515 C518 C520 C527 03-009-0075-90 CAP CER SMD 0.1uF 50V 20% Y5V 0603
TAPE
C503-510 C523 03-009-0113-90 CAP CER SMD 10nF 50V 10% X7R 0603
TAPE (RoHS)
C517 C522 03-009-0116-90 CAP CER SMD 33pF 50V 10% X7R 0603
(RoHS)
SMD DIODES
D509-513 04-006-0021-90 SMD DIODE LL4148 SOD80 (VISHAY)
(RoHS)
SMD TRANSISTORS
Q501-508 Q513-515 05-004-0018-90 SMD Transistor MMBT5551LT1G NPN
SOT-23 (ON) (RoHS
Q509-511 05-004-0037-90 TRANSISTOR SS PNP HFE30 250MHz
SPT DTA114EKAT146(RoHS)(ROHM)
JUMPERS
JMP2-3 JMP6-7 JMP10 JMP16 JMP18 17-016-0077-90 Jumper wire Dia. 0.5mm L=52.0mm
JMP22 JMP26-30 JMP33-36 JMP45 (RoHS)
JMP47 JMP51 JMP54 JMP57 JMP66
JMP69 JMP72 JMP73
JMP1 JMP4-5 JMP8-9 JMP11-15 JMP17 17-016-0080-90 Jumper Wire Dia. 0.6mm For L Smaller
JMP19-21 JMP23-25 JMP31-32 JMP37-44 than 14mm Roll (RoHS)
JMP46 JMP48-50 JMP52-53 JMP55-56
JMP58-61 JMP64-65 JMP68 JMP70-71
JMP74-92 JMP94-96
HEADPHONE BOARD
PCB ASSEMBLY 50-957-0326-90 C326 HEADPHONE BOARD ASSY
RESISTORS
R493-494 02-010-0042-90 RES MO 100 OHM 5% 2W AXIAL (RoHS)
CAPACTORS
C525 C526 03-001-0060-90 CAP CER 0.1uF 50V +/-20% Y5V RAD
ST5 (RoHS)
JACKS
M102 15-002-0029-90 PHONE JACK D6.3 1 PCB MOUNT
GOLD (RoHS)
M501 15-002-0039-90 PHONE JACK 3.5mm dia. H=5
CKX-3.5-49 GOLD (RoHS)
SMD CAPACTORS
C501-502 03-009-0111-90 CAP CER SMD 100pF 50V 10% X7R
0603 TAPE (RoHS)
JUMPERS
JMP62 JMP93 17-016-0080-90 Jumper Wire Dia. 0.6mm For L Smaller
than 14mm Roll (RoHS)
BIAS BOARD
PCB ASSEMBLY 50-963-0326-90 C326 BIAS BOARD ASSY
TRANSISTORS
Q160 Q360 05-001-0112-90 TRANSISTOR KSC2690AYSTU NPN
1.2A/160V TO-126 FAIRCHILD (RoHS)
