ALIGNMENT PROCEDURES
I. INITIAL
A. LOWEST VOLUME ADJUSTMENT
3. Connect a oscilloscope to L channel binding posts.
1. Tune the volume pot to lowest state.
2. Input a high voltage signal such as 5V from CD input.
4. Observing the oscilloscope,adjust VR301,make the output of speakers become to the
5. Adjusting VR302,make R channel output become to the lowest level by same way.
B. IDLING CURRENT
1. Connect a DC voltmeter toTP1 and TP2 ,adjust VR22 for 4-5mV reading on voltmeter.
2. Connect a DC voltmeter toTP3 and TP4 ,adjust VR12 for 4-5mV reading on voltmeter.
3. Level power on for a minimum of 5 minutes
II. FINAL ADJUSTMENT
Repeat procedure A and B for lowest volume level and idling current alignment
respectively.
TP1
TP2
TP3
TP4
VR22
VR12
VR301
VR302
MAIN BOARD
lowest level.
- 16 -
