NAD C 720BEE - Exploded View Parts List

REF.NO PART NO. DESCRIPTION Qty. REF.NO PART NO. DESCRIPTION Qty.
C001
66-047001-1
Chassis 1 F024
75-005001-0 Sleeve
2
C002
66-047003-0 Service Cover
1 F025
66-011006-0 IR Bracket
1
C003
66-001009-0 Clamper
2 F026
36-01012-00 VFD
1
C004
70-047001-1 Main Heat Sink
1 F027
75-047004-0 VFD Bracket
1
C005
66-001010-0 Transformer Bracket
1 F028 01-72003-01 VFD MODULE 1
C006
67-001011-0 Shielding Box
1 F029 01-72003-00 KEY BOARD 1
C007
18-72151-20 C Version Transformer
1 F030 01-72005-00 POTS BOARD 1
18-72151-10 AH Version Transformer
1 F031
66-011011-0 Connectible Bracket
1
C008
66-001008-0 Metal Disc
1
C009
94-001004-2 Label
1 R001
67-047002-1
Rear Panel˄AH˅
1
C010
66-001007-0 PCB Support
1
67-047003-1
Rear Panel˄C˅
1
C011
66-001011-0 Module Support
1 R002
37-01140-23 Tuner(AH)
1
C012
30-63200-00 Shorting Plug
1
37-01141-23 Tuner(C)
1
C013
75-010004-1 Foot
4 R003
11-01101-03 Rock Switch
1
C014
78-001002-0 Foot Pad
4 R004
17-07002-20
AC Outlet˄C˅
1
C015
70-014002-2 Heatsink1
7
17-07002-10
AC Outlet˄AH˅
1
C016
70-001002-0 Heatsink2
2 R005
15-02251-20
AC CORD˄C˅
1
C017 01-72002-00 Power Board 1
15-10121-10
AC CORD˄
AH˅
1
C018 01-72001-20
Main Board(C Version) R006
84-001002-0 Relief Bushing
1
01-72001-10 Main Board(AH Version) 1 R007 66-047004-0 Tuner Bracket 1
F001 67-047004-1 Fascia 1
F002 67-047005-0 End Cap L 1 T001 67-047001-0 Top cover 1
F003 67-047006-0 End Cap R 1
F004 66-047002-1 Subfascia 1 S001
61-023206-0 Self Taping Screws BTB3X6
4
F005 75-047003-0 Input Button Lozenge 1 S002 61-023208-0
Self Taping Screws BTB3X8
12
F006 77-001001-1 Tone Control Lozenge 1 C:14
F007 75-047001-1 Selector Knob 1 S003
61-022205-0 Self Taping Screws BTB2X5
8
F008 74-001001-1 Tone Defeat Button 1 S004
61-022206-6 Self Taping Screws BTB2.6X6
7
F009 73-014001-1 Tone Knob 3 S005
61-022205-6 Self Taping Screws BTB2.6X5
2
F010 73-014002-1 Volume Knob 1 S006
61-023106-0 Self Taping Screws STB3X6
58
F011 77-026001-0 Power Button Bezel 1 S007
61-023108-0 Self Taping Screws STB3X8
8
F012 77-026001-0 Power Button 1 S008
61-023506-0 Machine Screws MB3X6
4
F013 77-011004-1 Duo Bezel 2 S009
61-044514-0 Machine Screws MT4X14
2
F014 75-047005-0 Linked Goggle Bezel 2 S010
61-024108-0 Self Taping Screws STB4X8
4
F015 74-011001-1 Duo Buttons 4 S011
61-084108-0 Self Taping Screws STP4X8
6
F016 74-047001-0 Trio Buttons 2 S012
61-023204-0 Self Taping Screws BTB3X4
2
F017
74-001008-0 Quad Buttons
1 S013
64-108055-0 Bolt GB5781 M8X55
1
F018
75-047002-0 Selector Knob Bezel
1 S014
63-020820-1 Spring Washer GB93(8)
2
F019
75-003003-0 Bracket
2 S015
63-010816-0 Washer GB97(8)
2
F020
77-025001-1 Volume Knob Bezel
1 S016
62-010802-0 Nut GB6170(M8)
2
F021
76-011001-1 T172 Windows Lens
1 S017
62-010302-1 Nylon Nut (M3)
4
F022
76-003001-0 LED Lens
1
F023
66-018003-1 Phone Bracket
1
EXPLODED VIEW PARTS LIST
- 36 -
