NAD C 720BEE - Electrical Parts List

CIRCUIT NO. PART NO. DESCRIPTION
ICS
IC3, IC4, IC34, IC43 03-00082-00 TL082CP/D
IC44 03-01237-00 UPC1237HA
IC32, IC33 03-04094-00 CD4094/HEF4094
IC31 03-07313-00 NJU7313AL
DIODES
D13, D14, D15, D16, D17,
D23, D24, D25, D26, D27,
D37, D38, D39, D310,
D311, D312, D315, D42,
D43, D403, D412, D413,
D417, D418, D423, D428
33-44148-02 1N4148
D419, D420 33-44148-03 1N4148
D11, D12, D21, D22 33-14709-01 4.7V 0.5W
D313, D314 33-11600-01 16V 0.5W
D49 33-11800-01 18V 0.5W
D410, D411 33-12000-02 20V 0.5W
TRANSISTORS
QI2, Q12/1, Q16, Q26, Q44,
Q45, Q47, Q401, Q403,
Q411
31-01015-00 2SA1015 GR
QI1, Q11, Q17, Q21, Q27,
Q33, Q34, Q35, Q36, Q37,
Q38, Q39, Q43, Q46, Q48,
Q402, Q404, Q412, Q414,
Q416, Q417, Q421
31-01815-00 2SC1815 GR
Q12, Q15, Q22, Q25, Q102,
Q104, Q202, Q204
31-00970-00 2SA970 GR
Q13, Q14, Q23, Q24, Q101,
Q103, Q201, Q203
31-02240-00 2SC2240 GR
Q18, Q28 31-00647-00 2SB647A
Q19, Q29 31-00667-00 2SD667A
Q110, Q113, Q210, Q213,
Q42
31-01220-00 KSA1220
Q111, Q112, Q211, Q212,
Q116, Q216, Q41, Q413
31-02690-00 KSC2690
Q310 31-00363-00 2SK363
CAPACITORS
C18, C19, C28, C29, C45,
C46
05-22012-00 22p/100V ±10%
C360 05-10112-01 100p/100V± 10%
C302, C303, C361 05-22112-01 220p/100V ±10%
C12, C22, C335, C336,
C112, C113, C212, C213
05-47112-00 470p/100V ±10%
C438, C439, C440, C442 05-51112-00 510p/100V ±10%
C31, C32, C33, C34, C35,
C36, C37, C38, C39, C310
24-10161-01 100p/63V, ±10%
C311, C312 24-12261-00 1n2/63V, ±10%
C3, C357, C358, C41,
C443, C444
24-10461-00 0.1u/63V± 20%
C432 24-22461-00 0.22u/63V± 20%
C350 24-82161-00 820p/63V 10%
C349, C435, C436 24-10261-00 1n/63V 10%
C351, C352, C353, C354,
C355, C356, C362
24-10361-03 10n/63V 10%
ELECTRIAL PARTS LIST
PCB-1: MAIN BOARD
- 26 -
