CIRCUIT NO. PART NO. DESCRIPTION
ELECTRIAL PARTS LIST
C120, C220, C434 24-22312-04 22n/100V 10%
C119, C219, C327, C328 25-22361-05 22n/63V 5%
C118, C218 25-10461-04 0.1u/63V 5%
C17, C114, C115, C117,
C27, C214, C215, C217,
C319, C320, C321, C322,
C337, C338, C345, C346,
C411, C412,
25-10412-02 0.1u/100V 10%
C329, C330, C347 25-10461-07 0.1u/63V 5%
C331, C332, C348 25-22461-02 0.22u/63V 5%
C333, C334 25-95461-00 0.95u/63V 5%
C121, C122, C221, C222 25-10561-02 1u/63V 5%
C339, C340 06-10951-08 1u/50V 20%
C417, C418, C421 06-47951-00 4u7/50V 20%
C13, C14, C23, C24, C48,
C415, C416, C425, C426,
C428, C429, C430, C431,
C301
06-10051-00 10u/50V 20%
C11, C21 06-10051-08 10u/50V 20%
C12/1, C47, C49, C110,
C111, C210, C211, C323,
C324, C410
06-47021-00 47u/25V 20%
C325, C326, C341, C342 06-47021-06 47u/25V 20%
C103, C104, C203, C204,
C420
06-10111-00 100u/16V 20%
C15, C16, C25, C26 06-22161-00 220u/63V 20%
C43, C44 06-22151-00 220u/50V 20%
C413, C414 06-22131-00 220u/35V 20%
C422 06-33111-01 330u/16V 20%
C116, C216 06-22260-01 2200u/6.3V 20%
RESISTORS
R385, R386 07-10189-00
1.8¡ ±5% 1/6
R154, R155, R254, R255 07-10100-10
10¡ ±5% 1/4
R2 07-10100-00
10¡ ±5% 1/6
RI3 07-10330-00
33¡ ±5% 1/6
R115, R116, R215, R216 07-10330-10
33¡ ±5% 1/4
R14, R24, R416, R417,
R418, R419
07-10101-10
100¡ ±5% 1/4w
R363, RI6 07-10101-00
100¡ ±5% 1/6
R138, R238 07-10391-10
390¡ ±5% 1/4
R11, R139, R21, R239,
R31, R310, R311, R312,
R32, R33, R34, R35, R36,
R37, R38 R39
07-10471-10
470¡ ±5% 1/4w
R454, R455 07-10511-10
510¡ ±5% 1/4
R41, R42, R43, R44, R47,
R48, R49, R410, R411,
R413,
07-10681-10
680¡ ±5% 1/4w
R147, R247, R403, R405,
R406, R407, R474, R476
07-10102-10
1K¡ ±5% 1/4w
RI2 07-10102-00
1
¡ ±5% 1/6
R422, R423 07-10112-10
1.1K¡ ±5% 1/4
R424, R425 07-10132-10
1.3K¡ ±5% 1/4
R367, R368, R412 07-10202-10
2
¡ ±5% 1/4
R158, R258, R414, R428,
R440
07-10222-10
2.2K¡ ±5% 1/4w
RI4, R369, R370, R371,
R372, R373, R374, R375,
R376, R377, R378, R379,
R380
07-10472-00
4.7K¡ ±5% 1/6w
R401, R482 07-10472-10
4.7K¡ ±5% 1/4
- 27 -
