NAD C 720BEE - Page 28

CIRCUIT NO. PART NO. DESCRIPTION
ELECTRIAL PARTS LIST
R429 07-10512-10
5.1K¡ ±5% 1/4
w
R381 07-10512-00
5.1K¡ ±5% 1/6
w
R480 07-10622-10
6.2K¡ ±5% 1/4
w
R12/1 07-10682-10
6.8K¡ ±5% 1/4
w
R402, R469, R470, R471,
R404
07-10103-10
10K¡ ±5% 1/4w
R364, R365, R366, R449,
R450, R493, R494, RI5
07-10103-00
10K¡ ±5% 1/6w
RI1 07-10123-00
12K¡ ±5% 1/6
w
R148, R248, R441 07-10153-10
15K¡ ±5% 1/4
w
R387, R388 07-10203-00
20K¡ ±5% 1/6
w
R12/2, R15, R152, R25,
R252, R337, R341, R349,
R350, R351, R352, R353,
R354, R355, R356, R357,
R358, R382, R438, R468
07-10223-10
22K¡ ±5% 1/4w
R420, R421 07-10363-10
36K¡ ±5% 1/4
w
R487, R488 07-10393-10
39k¡ ±5% 1/4
w
R123, R223, R437, R473,
R477
07-10473-10
47K¡ ±5% 1/4w
R442, R445, R446, R436 07-10563-10
56K¡ ±5% 1/4
w
R448, R478, R479, R489,
R490, R491
07-10104-10
100K¡ ±5% 1/4w
R12, R22, R345, R346,
R457
07-10224-10
220K¡ ±5% 1/4w
R483, R451 07-10334-10
330K¡ ±5% 1/4
w
R435 07-10394-10
390K¡ ±5% 1/4
w
R156, R157, R256, R257,
R472
07-10474-10
470K¡ ±5% 1/4w
R486 07-10564-10
560K¡ ±5% 1/4
w
R142, R143, R242, R243 07-20220-10
22¡ ±5% 1/4
w
R107, R108, R207, R208 07-20390-10
39¡ ±5% 1/4
w
R103, R106, R111, R112,
R120, R203, R206, R211,
R212, R220, R219, R119
07-20820-10
82¡ ±5% 1/4w
R149, R249 07-21600-10
160¡ 1% 1/4
w
R327, R328 07-20181-10
180¡ 5% 1/4
w
R325, R326, R331, R332 07-23900-10
390¡ 1% 1/4
w
R383, R384 07-25600-01
560¡ 2% 1/6
w
R323, R324 07-27500-10
750¡ 1% 1/4
w
R329ˈR330
07-21501-10
1.5K¡ ±1% 1/4
w
R321, R322 07-23301-10
3.3K¡ 1% 1/4
w
R359, R360 07-20512-10
5.1K¡ 5% 1/4
w
R319, R320 N.I
R361, R362 07-21102-00
11K¡ ±1% 1/6
w
R492 07-24701-00
4.7K¡ ±1% 1/6
w
R121, R122, R221, R222 07-20104-10
100K¡ ±5% 1/4
w
R102,R104,R202,R204 07-20224-10
220K¡ ±5% 1/4
w
R340 07-20106-00
10M¡ ±5% 1/6
w
R146, R246 07-24301-20
4.3K¡ 1% 1/2
w
R19, R101, R105, R110,
R29, R201, R205, R210
07-20393-10
39K¡ 5% 1/4w
R150, R250 07-30109-01
1¡
/
1W 5%
R427 07-30220-01
22¡
/
1W 5%
R452, R453 07-30221-03
220¡
/
2W 5%
R128, R129, R228, R229 07-30331-00
330¡/0.5W 5%
R124, R125, R224, R225 07-30339-00
3.3¡/1/2W 5%
R126, R127, R226, R227 07-32701-02
2.7K¡ 2% 2
w
R144, R145, R244, R245 07-40687-03
0.068¡/3W 10%
R136, R137, R236, R237 07-50100-10
10¡/1/4W 5%
R151, R251 07-50100-01
10¡
/
1W 5%
R45, R46 07-50330-00
33¡/0.5W 5%
R130, R131, R230, R231 07-50820-02
82¡
/
1W 5%
- 28 -
