CIRCUIT NO. PART NO. DESCRIPTION
ELECTRIAL PARTS LIST
INDUCTORS
L11, L21 08-01010-00 1uH
POTS
RT31, RT32 09-01103-07 10KA
RT34 09-01203-06 20K MN
VR12, VR22 09-02301-00
300¡
VR301, VR302 09-02101-00
100¡
SWITCHS
SW31 11-02202-00 TONE DEFEAT
SW41 11-05202-12 SOFT CLIPPING
RELAYS
RL31, RL32, RL33, RL34
RL35, RL36
12-02101-02 JRC-27F/012/S
RL12/1, RL12/2 12-03102-00 JQX-115F/0242HS4AF
CONNECTERS
CZ34——CB31 14-72009-10
SCN 2.5A-9D
XHB2.5A-9Y26AWG;UL2468#;
130mm
TP1, TP2, TP3, TP4 13-10001-00 Test-1(R)
CB47 13-22510-00 XHB 2.5A-10A
CB45 13-22503-00 XHB 2.5A-3A
CB49 13-23904-00 VH 3.96A-4A
CZ37 13-22508-00 XHB 2.5A-8A
CZ36 13-21217-00 FPC1.25 17PIN
CZ35 13-21219-00 FPC1.25 19PIN
17-02002-00 SCJ351P00XS0B00
17-02002-01 ST-5037B-04
17-02001-03 SCJ349P00XS0B01
17-02001-04 ST-323B-04
RCA31, RCA32, RCA33,
RCA34
17-01004-05 4 holes red and white, gilt
RCA35 17-01001-11 1 hole red,AV-8.4-14,gilt
CB715 02-03005-20 C version
CB715 02-03005-10 AH version
LINKS
J7, J8, J9, J19, J20, J29,
J30, J35, J37, J53, J62, J64
,J65, J66, J67, J68, J71,
J72, J104, J105, J109,
J114, J115, J116, J117,
J118, J119, J121, J122,
J134, J136, J143, J147,
J148, J157, J160, J162,
J173, J175, J176, J178,
J179, J182, J183, J189,
J192, J200, J201, J202,
J205, J206, J207, J208,
J209, J210, J211, J212,
J218, J219, J222, J223,
J235, J236, J239, J244,
J247, J258, J260, J262,
J268, J271, J272, J273,
J281, J283, J284, J293,
J295, J297, J300, J302,
J303, J304
21-06500-00 L=5mm
PHONE1
PHONE2
