NAD C 720BEE - Page 30

CIRCUIT NO. PART NO. DESCRIPTION
ELECTRIAL PARTS LIST
J10, J11, J12, J13, J14,
J21, J34, J38, J39, J40,
J41, J43, J45, J46, J47,
J48, J49, J50, J52, J55,
J58, J59, J60, J85, J86,
J87, J93, J94, J120, J123,
J124, J125, J126, J127,
J128, J129, J130, J131,
J132, J137, J142, J158,
J166, J167, J168, J177,
J184, J190, J191, J193,
J197, J203, J204, J220,
J232, J233, J242, J243,
J246, J248, J263, J264,
J275, J301
21-06750-00 L=7.5mm
J4, J288, J296 21-10750-00 L=7.5mm
J6, J22, J33, J36, J51, J61,
J98, J99, J100, J101, J102,
J103, J106, J107, J108,
J133, J135, J140, J141,
J146, J169, J170, J172,
J180, J196, J199, J213,
J214, J215, J216, J217,
J228, J230, J231, J238,
J265, J266, J269, J270,
J274, J282, J290, J291,
J292, J294, J298, J299
21-06101-00 L=10mm
J159, J161, J165, J289 21-10101-00 L=10mm
J1, J23, J24, J25, J26, J27,
J28, J31, J32, J44, J56,
J144, J145, J149, J150,
J174, J181, J185, J186,
J188, J194, J195, J224,
J267, J286, J287
21-06121-01 L=12.5mm
J2, J16, J17, J18, J54, J63,
J74, J75, J76, J77, J78,
J79, J80, J81, J82, J83,
J84, J96, J97, J110, J112,
J113, J139, J156, J171,
J198, J226, J227, J245
21-06151-00 L=15mm
J5, J88 21-10151-00 L=15mm
J57, J111, J138, J151,
J152, J153, J154, J155,
J234, J259, J261, J279,
J280
21-06201-00 L=20mm
J42, J89, J91, J163, J250,
J251, J252, J253, J254,
J276, J277, J278
21-10201-00 L=20mm
J15, J69, J70, J90, J92,
J95, J164, J237, J240,
J241, J285
21-06251-00 L=25mm
J73, J249, J255, J256, J257 21-10251-00 L=25mm
J3 21-10301-00 L=30mm
CIRCUIT NO. PART NO. DESCRIPTIONS
TRANSISTORS
Q63, Q65 31-00970-00 2SA970 GR
Q64, Q66 31-00647-00 2SB647
Q67, Q68 31-00667-00 2SD667
Q61, Q62 31-00170-00 2SK170-BL
DIODES
D61, D62, D63, D64 33-44148-01 1N4148
PCB-7:OUT MODULE ; PCB-8: IN MODULE
- 30 -
