CIRCUIT NO. PART NO. DESCRIPTION
ELECTRIAL PARTS LIST
CAPACITORS
C63, C64 05-22012-01 22p/100V ±10%
C611 05-15012-00 15p/100V ±10%(OUT MODULE)
C611 05-40012-00 40p/100V ±10%(IN MODULE)
C610, C69 05-10112-00 100p/100V± 10%
C61, C62 05-22112-00 220p/100V ±10%
C65, C66, C67, C68 24-10461-00 0.1u/63V± 20%
RESISTORS
R617, R618, R619, R620 07-10100-00
10¡ ±5% 1/6
w
R615, R616 07-10330-00
33¡ ±5% 1/6w
R621 07-10121-10
120¡ ±5% 1/4w
R61, R62 07-10221-00
220¡ ±5% 1/6w
R67, R68, R611, R612 07-10102-00
1K¡ ±5% 1/6w
R613, R614 07-10103-00
10K¡ ±5% 1/6w
R69, R610 07-24300-00
430¡ 1% 1/6w
R65, R66 07-25600-01
560¡ 2% 1/6w(IN MODULE)
R63, R64 07-20105-00 1M ±5% 1/6W
CONNECTER
CB61 13-12509-01
9PIN CONNECTER
(IN MODULE TO CB32/ OUT
MODULE TO CB33)
CIRCUIT NO. PART NO. DESCRIPTION
TRANSISTORS
Q31, Q32, Q311, Q312 31-00108-01 PMBFJ108
DIEDES
D316, D317, D318, D319 33-44148-11 LL4148
RESISTORS
R335, R336 07-90680-01
68¡ ±5%
R317, R318 07-90471-01
470¡ ±5%
R333, R334, 07-90472-01
4.7K¡ ±5%
R347, R348, R391, R392 07-90104-01
100K¡ ±5%
R338, R339, R389, R390 07-90106-01
10M¡ ±5%
CAPACITORS
C317, C318 26-10151-01 100pF 50V ±5%
CONNECTER
CB34 13-12510-01 10PIN;glit
CIRCUIT NO. PART NO. DESCRIPTION
ICS
IC51 03-01117-01 AMS1117-5.0/LM1117MPX-5.0
TRANSISTORS
Q59, Q510, Q517, Q519 31-01015-00 2SA1015 GR
Q518, Q520 31-01815-00 2SC1815 GR
Q58 31-01220-00 KSA1220
DIODES
D513 33-24004-02 1N4004
D52 33-11500-01 15V 0.5W
D501, D54, D56 33-30142-00 DB104
D51, D55 33-30822-00 8A/200V
D531, D532 33-60116-00 TIC116D/BT151-500R
D53 33-13000-02 30V 0.5W
CAPACITORS
C535 05-47242-00 4n7p, 400V, ±20%
C56 25-22422-03 MKP62, 275V, 0.22uF 5%
C53 06-33151-01 50V/330u 20%
C51, C52 25-10322-00 10n/250V 10%
C536 06-10111-00 100u/16V 20%
C524 06-22251-00 2200u/50V 20%
C533 06-47211-00 4700u/16V 20%
C523 06-33251-00 3300u/50V 20%
C517, C518 06-15351-01 15000u/50V 10%
PCB-9: MUTE BOARD 01-72008-00
PCB-2: POWER BOARD
Ƹ
!
Ƹ
!
- 31 -
