NAD C 720BEE - Page 34

CIRCUIT NO. PART NO. DESCRIPTION
ELECTRIAL PARTS LIST
CIRCUIT NO. PART NO. DESCRIPTION
POT
RT33 09-01203-05 20KB
CONNECTER
CB31 13-22509-00 9PIN; 2.5mm
CIRCUIT NO. PART NO. DESCRIPTION
RESISTORS
R458, R459 07-30101-04
100¡ 2W ±5%
CONNECTER
JK41 17-02001-00 PH-2ASW
CZ45——CB45 14-72003-10
SCN 2.5A-3D;XHB 2.5A-3Y;
26AWG UL2468# ; WHITE; 400mm
LINKS
J401 21-06750-00 L=7.5mm
CIRCUIT NO. PART NO. DESCRIPTION
CONNECTER
CB59 13-23903-01
VH 3.96A-3A
(
এᥝЁ䯈䩜
)
CIRCUIT NO. PART NO. DESCRIPTION
TRANSFORMER 18-72151-20 TD-230-0150C (C VERSION)
TRANSFORMER 18-72151-10 TD-120-0150L (AH VERSION)
CONNECTERS
CB58——AC OUTPUT 14-72002-00
VH 3.96A-3Y; KST FDFD2-187(8);
18AWG; UL1672# ; RED; 100mm
CB58——CB59 14-72002-01
VH 3.96A-3Y; 18AWG UL1672# ;
RED; 100mm
CB56——POWER
SWITCH
14-72002-02
VH 3.96A-3Y; KST FDFD2-187(8);
18AWG UL1672# ; RED; 130mm
CB49——CB54 14-72004-00
VH 3.96A-4Y; 22AWG UL1672# ;
150mm
CZ37——CZ701 14-72008-10
XHB 2.5A-8Y; 26AWG UL2468# ;
WHITE; 500mm
CZ36——TUNER 14-72017-10 FPC; 17PIN; 180mm
CZ35——CZ702 14-72019-00 FPC; 19PIN; 710mm
AC CORD˄C˅
15-02251-20 WB01HS-001
AC CORD˄AH˅
15-10121-10 WB05HS-001
AC Outlet 17-07002-20 A302-D006-0P
AC Outlet 17-07002-10 JY0647A
Rock Switch 11-01101-03 RF-1003-BB2
Ferrit Ring 19-26030-00 F5B RH 26*30*16
TUNER
TUNER MODULE 37-01140-23 KST-MB114MA0-23
TUNER MODULE 37-01141-23 KST-MB114MA1-23
TUNER ANTENNA˄AM˅
30-37300-10 LS0146BL-X000101-0
TUNER ANTENNA˄FM˅
30-37300-00 HAN-001
TV Matcher 30-87200-00 IF-11/ZB-6
NOTES: AH C
TRANSFORMER
TD-120-0150L TD-230-0150C
AC CORE
WB05HS-001 WB01HS-001
TUNER MODULE
KST-MB114MA0-23 KST-MB114MA1-23
PCB-9: HEADPHONE BOARD
PCB-6: AC OUT BOARD
OTHERS
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
- 34 -
