Pin
No.
Code
Function
Input /
Output
Description
7 Not Used ―――
*Note : Never use pin labeled " NOT
USED "
8 Not Used ――― *Note : Never use pin labeled " NOT
USED "
9
EMG - INB
Emergency
Stop B
Input External Power
Source input for
Emergency Stop
Signal or Emergency
Stop Signal OFF
(Open)
External Power Source input for
Emergency Stop Signal or Emergency
Stop Signal OFF (Open).
Normal Operation ON (Closed),
Emergency O
FF (Open).
This signal is active only when connecting
the Safety Relay Box (Sold separately) to
the CONTROLLER.
10 MT - CNB Motor Connect
Contact B
Output
Continuity, OFF
(Open), between
Pin No. 2 and Pin
No. 10 the motor is
connected
When there is continuity, OFF, between
Pin No. 2 and Pin No. 10, the selected
motor is connected, if no continuity the
motor is disconnected or the motor cord is
broken.
11 SAFE - 1B Safety Relay
Contact 1B
Output
Pin No. 3 and Pin
No. 11 continuity ON
(Closed) Safety Relay
is OFF
When there is continuity between Pin
No. 3 and Pin No. 11 ON (Closed) Safety
Relay is OFF (System Stopped). If there
is no continuity Safety Relay is OFF
(Open) Normal Operation.
12 SAFE - 2B Safety Relay
Contact 2B
Output
Pin No. 4 and Pin
No. 12 continuity
ON (Closed) Safety
Relay is OFF
When there is
continuity between Pin No.
4 and Pin No. 12 ON (Closed) the Safety
Relay is OFF (System Stopped). If there
is no continuity, Safety Relay is OFF
(Open) Normal Operation.
13 AUTO - Control Mode
AUTO Signal (-)
Output
Control Mode AUTO
Pin No. 5 and Pin No.
13 are ON (Closed)
When Control Mode AUTO is being used,
Pin No. 5 and Pin No. 13 are ON (Closed).
14 PWON - CONTROLLER
Power Source
Monitor (-)
Output
ON (Closed) :
Main Power Supply
is connected
OFF (Open) :
Main Power Supply
is disconnected
If the Main Power Switch is ON, Pin No. 6
and Pin No. 14 are ON (Closed).
15 Not Used ―――
*Note : Never use pin labeled " NOT
USED "
