87
English
18 - 3 Contents of Parameters
② Setting AUTO Mode for Motor Speed Control
Allows the setting of the Motor Speed while in AUTO Mode. This parameter selects between speed control with
the Motor Speed Adjustment Button (SPEED
, ) of the Control Panel or by External Command Signal
through External Input / Output Connector A.
Table. 10
Parameter Set Contents
Set the Motor Rotation Speed by External Command Signal through External Input
/ Output Connector A.
Set the Motor Rotation Speed by Motor Speed Adjustment Button (SPEED , )
via the Control Panel.
Parameter Set Contents
Fixed Motor Speed is not enabled.
Fixed Motor Speed is enabled.
③
Setting Fixed Motor Speed
・Allows the Motor speed to be ¿xed.
・Proactively prevents inadvertent change in speed.
・The Fixed Motor Speed can set by Control Mode MANUAL or AUTO.
Table. 11
CAUTION
The operating parameters can be preset depending on the application requirements.
The operating parameter presets ( " Setting of Error Output Mode ", " Setting AUTO mode for Motor
Speed Control ", " Setting Fixed Motor Speed ", " Setting Maximum Motor Speed ", " Selection of
External Speed Control Mode ", " Selection of External Motor Start Signal Control Mode ",
" Setting of Motor Acceleration and
Deceleration Time " and " Temporary Motor / Spindle Operation
if FAN has Stopped (80 Square Type)" ) are retained in non-volatile memory and will be maintained
even if power is disconnected.
Please operate only after con¿rming contents of parameter settings.
CAUTION
If you set the rotation speed higher than the rotation speed set at , rotation speed will be set
according to
.
The following parameters can be set.
①
Setting of Error Output Mode
Table. 9
Parameter Set Contents
Error Occurred : Signal is OFF (Open).
Error Occurred : Signal is ON (Closed).
・Selection of the error output mode is on Pin No. 8: ERR of External Input / Output Connector A.
・When an error occurs the output can be select to ON (Closed) or OFF (Open).
・Signals can be output according to the required machine control logic of the system.
To Next Page
