88
・When setting by Analog Signal , use the External Input / Output Signal " Motor Speed Control Voltage (Pin
No. 23 : VR) ".
・
When setting via the Pulse Signal , use the External Input / Output Signal " Count Pulse Signal for
Setting Motor Speed (Pin No. 3 : CNT_IN) " and External Input / Output Signal " UP / DOWN Signal for
Setting Motor Speed (Pin No. 15 : UD_IN) ". The motor speed change per pulse is 100 min
-1
(rpm).
External Input / Output Signal UP / DOWN Signal for Setting Motor Speed is as follows:
OFF (Closed) : Rotation speed decreases
ON (Open) :
Rotation speed increases
・
When setting by Speed Point Signal , select the Speed Point - by using the combination of
Speed Point Select 0 (Pin No.17 : SEL0) and Speed Point Select 1 (Pin No. 5 : SEL1).
Speed Point SEL1 (Pin No. 5) SEL0 (Pin No. 17)
OFF (Open) OFF (Open)
OFF (Open) ON (Closed)
ON (Closed) OFF (Open)
ON (Closed) ON (Closed)
・Can setting the different rotation speed in 4 Speed Points
- .
Speed ranges from 1,000 - 40,000min
-1
(rpm)
can be set.
⑤
Selection of External Speed Control Mode
When Control Mode is in AUTO, it is possible select the External Speed Control Mode from Analog Signal
, Pulse Signal , or Speed Point Signal . Speed preset in the control according to - .
Parameter Set Contents
Set speed by Analog Signal.
Set speed by Pulse Signal.
Set speed by Speed Point Signal.
CAUTION
Actual motor rotation speed of the motor will be limited, based on maximum motor rotation speed
of the type of motor connected.
Table. 13
Table. 14
④ Setting Maximum Motor Speed
・Maximum Motor Speed can be set.
・Allows a safe maximum rotational speed limit depending on the application.
・The Maximum Motor Speed can set by Control Mode MANUAL or AUTO.
Parameter Set Contents
Setting of Maximum Motor Speed is not enabled.
Setting of Maximum Motor Speed is enabled.
Table. 12
CAUTION
Actual motor rotation speed of the motor will be limited, based on maximum motor rotation speed
of the type of motor connected.
