② Setting AUTO Mode for Motor Speed Control
③
Setting Fixed Motor Speed
Procedure
1. Push the Start / Stop Button (START / STOP).
2.
is displayed. This indicates that speed control by the Motor Speed Adjustment Button
(SPEED
, ) is disabled. The External Command Signal Control will be operational.
3. Push the Start / Stop Button (START / STOP).
4.
is displayed. This indicates that speed control is changeable by the Motor Speed
Adjustment Button (SPEED
, ).
5. You can cycle through the choices by pushing the Start / Stop Button (START / STOP).
6. Push the Error Reset Button (RESET) to send the settings to memory,
will be displayed.
7.
If you desire to set other parameters, press the Motor Speed Adjustment Button (SPEED , )
to select the parameter that needs to be set.
8. When you are ¿nished setting parameters, press the Error Reset Button (RESET), then turn the
Main Power Switch OFF.
CAUTION
Actual motor rotation speed of the motor will be limited, based on maximum motor rotation speed
and the type of motor connected.
Procedure
1. Push the Start / Stop Button (START / STOP).
2.
is displayed. This indicates that Fixed Motor Rotation Speed can not be set.
3. Push the Start / Stop Button (START / STOP).
4. The setting motor rotation speed displayed on Digital Speed Indicator.
5.
Push the Motor Speed Adjustment Button (SPEED
, ) to set the motor rotation speed.
The Moto Rotation Speed range is 1,000 - 40,000min
-1
(rpm)
6. Push the Error Reset Button (RESET) to send the settings to memory,
will be displayed.
7.
If you desire to set other parameters, press the Motor Speed Adjustment Button (SPEED , )
to select the parameter that needs to be set.
8. When you are ¿nished setting parameters, press the Error Reset Button (RESET), then turn the
Main Power Switch OFF.
④
Setting Maximum Motor Speed
CAUTION
Actual motor rotation speed of the motor will be limited, based on maximum motor rotation speed
and the type of motor connected.
Procedure
1. Push the Start / Stop Button (START / STOP).
2.
is displayed. This indicates that Maximum Motor Rotation Speed can not be set.
The Maximum Motor Rotation Speed is 40,000min
-1
(rpm).
3. Push the Start / Stop Button (START / STOP).
4. The Maximum Motor Rotation Speed is displayed on Digital Speed Indicator.
5.
Push the Motor Speed Adjustment Button (SPEED
, ) to set the motor rotation speed.
The Moto Rotation Speed range is 1,000 - 40,000min
-1
(rpm).
6. Push the Error Reset Button (RESET) to send the settings to memory,
will be displayed.
7.
If you desire to set other parameters, press the Motor Speed Adjustment Button (SPEED , )
to select the parameter that needs to be set.
8. When you are ¿nished setting parameters, press the Error Reset Button (RESET) , then turn
the Main Power Switch OFF.
