93
English
⑥ Selection of External Motor Start Signal Control Mode
⑦
Setting of Motor Acceleration Time and Deceleration Time
Procedure
1. Push the Start / Stop Button (START / STOP).
2.
is displayed. This indicates that motor startup and setting the rotation direction can not
performed simultaneously.
3. Push the Start / Stop Button (START / STOP).
4.
is displayed. This setting is right hand rotation with motor startup by Rotation Command
(Pin No. 14 : START) or left hand rotation with motor startup by Rotating Direction (Pin No. 2 :
DIR_IN) are can be set.
5. You can cycle through the choices by pushing the Start / Stop Button (START / STOP).
6. Push the Error Reset Button (RESET) to send the settings to memory,
will be displayed.
7.
If you desire to set other parameters, press the Motor Speed Adjustment Button (SPEED , )
to select the parameter that needs to be set.
8. When you are ¿nished setting parameters, press the Error Reset Button (RESET), then turn the
Main Power Switch OFF.
Procedure
1. Push the Start / Stop Button (START / STOP).
2.
is displayed. In this setting, the Acceleration Time and Deceleration Time is 2 seconds,
which is the factory default time setting.
3. Push the Start / Stop Button (START / STOP).
4. Alternately displayed
and the Acceleration Time / Deceleration time (default 2 secons).
5.
Push the Motor Speed Adjustment Button (SPEED
, ) select the setting time. (The
Acceleration Time / Deceleration time.) (Unit : Seconds)
6. Push the Error Reset Button (RESET) to send the settings to memory,
will be displayed.
7.
If you desire to set other parameters, press the Motor Speed Adjustment Button (SPEED , )
to select the parameter that needs to be set.
8. When you are ¿nished setting parameters, press the Error Reset Button (RESET) , then turn
the Main Power Switch OFF.
⑧
Temporary Motor / Spindle Operation if FAN has Stopped (80 Square Type)
Procedure
1. Push the Start / Stop Button (START / STOP).
2.
is displayed. This setting is for FAN (80 Square Type) and the motor / spindle is stopped.
3. Push the Start / Stop Button (START / STOP) again.
4.
is displayed. This setting is for temporary motor / spindle operation when FAN (80 Square
Type) has been stopped due to the FAN failure.
An Output to the External Warning Signal (WARNING) will be sent to the CONTROLLER.
5. Push the Start / Stop Button (START / STOP).
6.
is displayed. This setting is for temporary motor / spindle operation when FAN (80 Square
Type) has been stopped due to a FAN failure. An Output to the External Warning Signal
(WARNING) will be sent to the CONTROLLER. If other Warning Codes occur other than "AF",
these signals will be sent to the CONTROLLER (External Warning Signal) (Warning).
7.
Push the Error Reset Button (RESET).
8.
If you desire to set other parameters, press the Motor Speed Adjustment Button (SPEED
, )
to select the parameter that needs to be set.
9. When you are ¿nished setting parameters, press the Error Reset Button (RESET), then turn the
Main Power Switch OFF.
To Next Page
