Accelaterm
®
Installation and Service Manual 2
FCC WARNING
Changes or modifications to this unit not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
NOTE
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harm-
ful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which the user will be required to correct the interference at his own expense.
Shielded cables must be used with this unit to ensure compliance with the Class A FCC limits.
DISCLAIMER
Continental Access makes no representations or warranties with respect to the contents hereof and specifically
disclaims any implied warranties of merchantability or fitness for any particular purpose. Further, Continental
Access reserves the right to revise this publication and to make changes from time to time in the content hereof
without obligation of Continental Access to notify any person of such revision or changes.
Information furnished by Continental Access is believed to be accurate and reliable. However, no responsibility
is assumed by Continental Access for its use; nor for any infringements of other rights of third parties which may
result from its use. No license is granted by implications or otherwise under any patent or patent rights of Conti-
nental Access.
Copyright © 2013 by Continental Access. All rights reserved. No part of this publication may be reproduced,
transmitted, transcribed, or stored in a retrieval system, without the prior written permission of Continental Ac-
cess, 355 Bayview Avenue, Amityville, NY 11701. 631-842-9400
A NAPCO SECURITY TECHNOLOGIES COMPANY
To terminate more than two conductors or con-
ductors of different wire sizes to a terminal, use the
"pigtail" type wiring method as shown at right. Use
insulated wire for the pigtail, and firmly secure the
conductors to the pigtail using an appropriate wire
nut or crimp connector for the number and gauge of
conductors used.
IMPORTANT WIRING METHODS
Incorrect
Correct -- Use pigtail and wire nut / crimp connector
PIGTAIL
WIRE NUT
OR CRIMP
CONNECTOR
PIGTAIL
For single-conductor terminal
blocks (like the type shown at left),
to terminate more than one conduc-
tor to a terminal, use the wiring
methods shown at right:
WIRE NUT OR
CRIMP
CONNECTOR
PIGTAIL
Correct -- Single incoming and/or pigtail with wire nut / crimp connectors
In
For "barrier" type terminal
blocks (like the type shown at left),
to terminate two conductors to a
terminal, use the wiring methods
shown at right:
Correct -- Separate incoming and outgoing conductors
In Out
Incorrect
Incorrect
In Out
