Accelaterm
®
Installation and Service Manual 34
Combined Standby Current
Battery AH
3.5
Hours
4
Hours
12
Hours
24
Hours
Two 12AH 24 5A 4.5A 1.8A 1A
One 12AH 12 2.5A 2A .9A .5A
SPECIFICATIONS
POWER RATINGS
The Accelaterm contains a power supply that switches between 120VAC/60Hz for the USA, or 230VAC/50Hz for the EU.
Voltage Input
Current
(Maximum)
115VAC 2.0 Amperes
230VAC 1.0 Amperes
Output Rating: 12V regulated maximum 5A.
Standby Current
Charger Board + Interface Board +
Memory Processor Board + Relay
Board
95mA + 30mA for
each energized relay
board relay
Expansion Board 20mA
Interface Board Repeater Module 20mA
Ethernet Board 120mA
Interface Board and Expansion Board Output Ratings
Interface Board and Expansion
Board reader power
12V, 350mA each
Interface Board and Expansion
Board LED current
12V, 100mA each
Interface Board and Expansion
Board 5V output power
5V, 1.5A total
Interface Board Supervised
Alarm Inputs (J2-J9)
5V, 5mA each
Relay Board Output Ratings
Relay Coil current 30mA each
Relay contact current (dry) 28VAC/DC, 2 Amps each
Relay output current (wet) 12V, 2 Amps each
ACC PWR OUT 12V, 600mA combined
Power Supply Ratings
Total 12V current from power supply not
including charge current
5A
Maximum Battery charging current 1.5A
