Accelaterm
®
Installation and Service Manual 32
SPECIFICATIONS
Specifications Quantity Comments
CardAccess Compatibility Full function on or off line
Card Capacity
200K
650K
Base 4M Memory/ 5-digit Cards
Full 20M Memory/19-digit Cards
Database RAM
Each option Module adds 8M
4M
12M
20M
4M Base
One Option Memory Module
Two Option Memory Modules
Card Reader Capacity
Eight
Sixteen
Base Unit
With Eight Reader Expansion via Plug-over PCB
Card Reader Power 12VDC, 350mA max each
Reader Types Wiegand / Proximity, Magnetic Stripe (not evaluated by UL), Prox and PIN
Access Modes Card Only, Unique PIN only, Card and PIN, Free Access
Reader LED Outputs Active low, one per Reader (50mA limit)
Keypad Capacity
Eight
Sixteen
Wiegand Format ONLY
with Eight Reader Expansion via Plug-over PCB
Number of Doors
Eight
Sixteen
with Eight Reader Expansion via Plug-over PCB
Output Relays - Form C
16 plus
Console
Sixteen relays configurable to route Lock Power
Relay Circuit Protection All Relays - 2.5A PTC Limited
Internally Backed 12V Lock Power Eight 8 Outputs at 2A max each from overall current rating
Relay Expansion 48 using External I/O Expansion Units
Supervised Inputs ..................................Alarm
Door Sense, Bypass
Door Sense, Bypass
Eight
Sixteen
Sixteen
All inputs Host configurable as dry contact.
Base Interface Board.
With Eight Reader Expansion via Plug-over PCB.
Tamper Switch One Pre-assigned
Communication with Host and Downstream
Panels
Ethernet 10/100Base-T (Host with Plug-in Module)
Full Duplex EIA/TIA-485 (Host or Downstream Panels)
Addressing Two BCD Format Switches
Downloadable Firmware
With fast Server -
Loaded to FLASH Memory in 2 seconds or less.
Diagnostic LED's ...............................Interface
Processor/Memory PCB
Charger/Isolator
9
2
2
Ethernet TX/RX, Repeater TX/RX, Okay Blinky, Logic Power,
Reset Warning, 12V Power, 12V [Battery] Low Warning.
Reset, Board Power
Power (Main), 12V (Main or Battery)
Auxiliary Serial Ports I2C-bus Format via 6-Pin Modular Jack
Accessory 12V Output 600mA combined from Relay Board, PTC Limited
Accessory 5V Power 5V total 1.5A maximum
Memory Battery Backup
1 month nominal at 25°C (field-replaceable by qualified service personnel
only)
Backup Power Two 12AH Batteries for 3.5 hours battery backup (full load)
Power Supply Voltage Switch selectable 120/230VAC 50-60 ~ 200W
Dimensions
Height 24-3/8" (620mm), Width 16-3/8" (416mm), Depth
5" (127mm)
Weight 38 pounds (17.3Kg) with two 12AH battery installed
