23 Accelaterm
®
Installation and Service Manual
ACCESSORY POWER
The ACCESSORY POWER terminal strip (labeled "JP2" and
"ACC PWR OUT") provides battery backed +12VDC power
outlets for auxiliary devices. This terminal strip is located in
the lower middle of the Relay Board.
Table 12 lists the ACC PWR OUT terminal strip pin numbers
and their associated functions.
Note: +12VDC current draw is limited to a total maximum
of .75 Amps for accessories.
WARNING
Observe Positive and Negative wire polarity be-
tween accessory devices and the Accelaterm.
ACCESSORY POWER
Table 12 - ACC PWR OUT
Terminal Strip Functions
Pin Function
1 +12
2 GND
3 +12
4 GND
