Napoleon HD46NT - Installation Overview; Using Non-Combustible Material

W415-1347 / A / 03.19.15
3
EN
1.0 INSTALLATION OVERVIEW
Mantel, see “MINIMUM
MANTEL CLEAR-
ANCES” section.
Enclosures, see the
section “MINIMUM
CLEARANCES TO
COMBUSTIBLE
ENCLOSURES”
section for drywall (or
other combustible
material).
Framing, see
“FRAMING”
section.
Side
Wall
Venting, see “VENTING”
section.
Framing, see “FRAMING”
section.
Enclosures, see the
section “MINIMUM
CLEARANCE TO COM-
BUSTIBLE ENCLO-
SURES” section for
non-combustible materials
such as tile, marble,
granite, etc.
Rating plate, see “RATING
PLATE INFORMATION”
section.
SAFETY BARRIER
1.1 USING NON-COMBUSTIBLE MATERIAL
19.0 HD40 ACCESSORIES 56
20.0 HD40 ACCESSORIES (PAGE 2) 57
21.0 HD46 OVERVIEW 58
22.0 HD46 VALVE TRAIN ASSEMBLY 59
23.0 HD46 ACCESSORIES 60
24.0 HD46 ACCESSORIES (PAGE 2) 61
25.0 TROUBLESHOOTING 62
26.0 WARRANTY 64
27.0 SERVICE HISTORY 65
28.0 NOTES 66
