Napoleon HD46NT - Page 60

W415-1347 / A / 03.19.15-
60
EN
23.0 HD46 ACCESSORIES
46
43
45
1
33
34
36
35
37
38
39
40
41
42
44
46
43
45
1
33
34
36
35
37
38
39
40
41
42
44
GD843KT GD847KT PRPHR46
HDF46
PRPH46
SAFETY
SCREEN
11 04 14
ITEMS MAY NOT APPEAR EXACTLY AS ILLUSTRATED
REF NO. PART NUMBER DESCRIPTION STOCKED 1 W565-0175 SAFETY SCREEN (HDF46) 33 W475-0703 LEFT SIDE BRICK PANEL (GD843KT) 34 W475-0691 REAR BRICK PANEL (GD843KT) 35 W475-0692 RIGHT SIDE BRICK PANEL (GD843KT) 36 W475-0697 LEFT SIDE MAYAN BRICK PANEL (GD847KT) 37 W475-0695 REAR MAYAN BRICK PANEL (GD847KT) 38 W475-0696 RIGHT SIDE MAYAN BRICK PANEL (GD847KT) 39 W090-0161 LEFT SIDE PORCELAIN PANEL (PRPH46)
REF NO. PART NUMBER DESCRIPTION STOCKED 40 W090-0165 REAR PORCELAIN PANEL (PRPH46) 41 W090-0162 RIGHT SIDE PORCELAIN PANEL (PRPH46) 42 W090-0173 LEFT SIDE PORCELAIN PANEL (PRPHR46) 43 W090-0177 REAR PORCELAIN PANEL (PRPHR46) 44 W090-0174 RIGHT SIDE PORCELAIN PANEL (PRPHR46) 45 W010-3370 FRAME ASSEMBLY (HDF46) 46 W010-3371 TRIM ASSEMBLY (HDF46)
