Napoleon LD485RB - Tray and Holder Installation

26
www.napoleongrills.com
17. Grease Tray and Holder Installaon
Clip the wire grease tray holder into the two holes located in the center of the back panel. Place the aluminum grease tray
into the grease tray holder.
18. Drip Pan Installaon
Slide drip pan into rear of base as shown. Ensure dip pan rides along rails on boom of base.
disposable grease tray
