2-6 Installation
2.16 Schwarzbeck Model
HXYZ 9170 Triple
Loop Antenna
Remote Cable
configuration for
PMM 7010
The following figure shows the HXYZ 9170 Triple Loop Antenna remote
cable pin configuration. This cable can be requested to N
arda or arranged
locally.
Fig. 2-2 HXYZ 9170 remote cable configuration for PMM 7010
