Installation 2-7
2.17 PMM LISNs
Three Phase
Remote Cable
configuration
for PMM 7010
(L3-25 excluded)
The following figure shows the LISN remote cable pin configuration. The
cable can be requested to N
arda or arranged locally.
Fig. 2-3 PMM LISN three phase remote cable configuration for PMM 7010
