2-8 Installation
2.18 PMM L3-25
Remote Cable
configuration
for PMM 7010
The following figure shows the LISN remote cable pin configuration. The
cable can be requested to N
arda or arranged locally.
Fig. 2-4 PMM L3-25 remote cable configuration for PMM 7010
