9 Cleaning, maintenance, repair
32 RadMan 2LT/2XT
9.4 Changing the batteries
The batteries can be changed by the user. It may be necessary to change the
batteries if the operating duration with fully charged batteries significantly
decreases.
NOTE: Observe the regulations regarding the disposal of batteries, both
rechargeable and non-rechargeable (see Disposal on page 34).
Use suitable rechargeable batteries: 2x NiMH, type AA (Mignon).
1. Open the protective cap (1) on the bottom end of the RadMan 2.
2. Loosen 2 Allen screws (2) with the Allen wrench (1.5 mm).
3. Remove the battery cover (3).
4. Remove and replace the rechargeable batteries (4).
5. Mount the battery cover and tighten the Allen screws.
6. Close the protective cap.
WARNING
Wrong polarity
The batteries can explode if installed with the wrong polarity.
This will destroy the device.
Observe the marking for the plus and minus pole in the battery
compartment.
